Description

The TRICONEX T8231 module is a component in the Triconex Safety Systems product line, primarily designed for use in industrial automation and safety-critical systems.

Product Name

TRICONEX T8231 I/O Module

Product Description

The TRICONEX T8231 is a digital input/output (I/O) module designed for integration into the Triconex Safety Systems. These systems are used in applications that require high levels of safety, reliability, and fault tolerance, such as in the process industries (e.g., oil & gas, petrochemical, chemical plants, power generation, etc.). The T8231 module enables the connection of digital field devices to the Triconex safety controllers.

The T8231 provides a robust interface for monitoring and controlling discrete digital signals in safety-critical environments, allowing the monitoring of digital inputs and controlling digital outputs as part of a larger safety system architecture. It is part of the Triconex Tricon family of safety systems, which is known for its fault-tolerant, high-availability features.

Product Parameters and Specifications

The specific parameters and specifications of the T8231 module are as follows:

• Input Type: Digital Inputs (typically 24V DC or 120V AC, depending on the configuration).
• Output Type: Digital Outputs (dry contact or other configurations).
• Channels: The T8231 can have multiple input and output channels, commonly 32 digital I/O points (16 inputs, 16 outputs), but configurations may vary.
• Power Supply: The module typically operates with a 24V DC power supply, but the exact requirements can depend on the configuration of the module.
• Field Wiring: Screw terminal connectors for field wiring to I/O devices.
• Isolation: The T8231 module provides optical isolation between field devices and the system for enhanced reliability and safety.
• Safety Certifications: Complies with IEC 61508, ISA 84.00, and SIL (Safety Integrity Level) 3 standards for safety-critical applications.
• Redundancy: Typically designed to support redundancy configurations (e.g., dual-redundant power supplies, processor redundancy) to enhance system reliability and availability.
• Diagnostics: The module provides built-in diagnostics for fault detection and isolation, ensuring that any issues can be identified quickly and effectively.
• Environmental Conditions: Designed to operate in industrial environments with temperature ranges from -40°C to 70°C, as well as humidity and vibration tolerance.
• Communication: The module communicates with other components in the system (such as Tricon controllers) via industrial communication protocols.

Product Use

The T8231 module is primarily used in safety-critical control systems, where reliable and safe operation is paramount. Key applications include:

• Process Automation: Used in critical process control and monitoring, especially where safety is a key concern (e.g., pressure, temperature, and flow monitoring).
• Emergency Shutdown Systems (ESD): Integrated into emergency shutdown systems to detect hazardous conditions and take corrective actions to avoid unsafe operations.
• Fire and Gas Detection Systems: Used in conjunction with fire and gas detectors to initiate shutdowns or corrective actions in response to dangerous conditions.
• Shutdown and Alarm Systems: Provides digital I/O for monitoring alarms and executing shutdown sequences in case of critical faults.
• Safety Instrumented Systems (SIS): The T8231 can be part of a Safety Instrumented System, where it plays a key role in reducing risk in accordance with safety standards (e.g., SIL 3 compliance).

Key Features and Benefits

• Fault Tolerance: The module is designed for high availability, ensuring that it continues to function correctly even in the presence of component failures.
• Redundancy and High Availability: Supports redundant configurations for greater fault tolerance, ensuring no single point of failure.
• Compliance with Safety Standards: Certified for safety-critical applications and supports SIL 3 compliance for high-risk industrial environments.
• Easy Integration: The T8231 module integrates easily with other Triconex system components, allowing for straightforward system expansion and configuration.
