Description

The TRICONEX 3805E module is part of the Tricon system, which is designed for safety and high availability in industrial automation.

### Product Name:

**TRICONEX 3805E Module**

### Product Description:

The TRICONEX 3805E is a digital input and output module designed for use in critical safety applications. This module is part of the Tricon family of safety systems, known for their reliability and fault tolerance in process control environments. The module serves to interface with various field devices, facilitating signal processing and integration within complex control systems.

### Product Parameters:

– **Type:** Digital Input/Output Module
– **Architecture:** Redundant configuration for enhanced reliability
– **Communication Protocol:** Supports various protocols depending on system configuration

### Specifications:

– **Input Voltage Range:** 24V DC (typical for digital I/O)
– **Input Configuration:** Can handle multiple digital inputs (usually up to 32 inputs)
– **Output Configuration:** Digital output capabilities, typically also supporting up to 32 outputs
– **Isolation:** Designed with electrical isolation for safety
– **Operating Temperature Range:** Typically between -20°C to +60°C (depending on the operating environment)
– **Weight:** Approximately 1.5 kg (may vary based on configuration)
– **Dimensions:** Specific dimensions can vary, but usually compact for ease of integration into control panels

### Product Use:

The TRICONEX 3805E module is commonly used in industries such as oil and gas, chemical processing, power generation, and manufacturing, serving critical safety functions including:

– **Emergency Shutdown Systems (ESD):** To ensure safe shutdown of processes in case of emergencies.
– **Process Control Systems:** For monitoring and controlling various aspects of industrial processes.
– **Safety Instrumented Systems (SIS):** To fulfill the safety integrity levels (SIL) required in hazardous operations.
– **Signal Processing:** Interfacing with field devices such as sensors, switches, and actuators to ensure accurate data collection and process control.

The module is crucial for realizing high safety standards and operational reliability in automated industrial settings, allowing for real-time monitoring and control to protect both personnel and equipment.
