The TRICONEX 3625C1 is a module designed by Emerson as part of its Triconex Safety System, which is a part of their Process Safety Management solutions.

Product Name:

TRICONEX 3625C1

Product Description:

The TRICONEX 3625C1 is a Digital Input Module designed for use with the Triconex Safety Instrumented System (SIS). Triconex is widely used in critical process industries where safety and reliability are of utmost importance. The 3625C1 module allows the integration of field devices (such as sensors and switches) that provide input signals to the system for processing and safety monitoring.

This module is part of the broader Triconex series, known for its fault-tolerant, redundant architecture that ensures continuous, safe operation of systems in industries like oil and gas, chemicals, power generation, and other high-risk process environments.

Product Parameters:

• Module Type: Digital Input Module
• Input Type: Discrete (Digital) inputs
• Input Channels: Typically, the 3625C1 module offers 32 digital input channels, though this can vary depending on specific configurations.
• Input Signal Types: Typically designed to handle signals such as:
  • 24V DC input signals (e.g., from sensors or switches)
  • Dry contact signals
  • Normally open (NO) or normally closed (NC) contacts
• Isolation: Provides galvanic isolation between input channels and the system to ensure protection from electrical faults or noise.
• Input Voltage Range: Typically 24V DC nominal, with some tolerance based on the field wiring standards.
• Input Current: Depending on the device connected to the input, typically a low current draw (measured in mA) for each input.
• Signal Type: The inputs typically work in binary states (on/off) or open/closed switch configurations.

Specifications:

• Voltage Supply:
  • Commonly operates at 24 V DC.
• Isolation:
  • Offers galvanic isolation for each input, ensuring the protection of the safety system and field devices.
• Response Time:
  • Fast input response times for safety-critical applications (typically in the millisecond range).
• Reliability:
  • The Triconex system, including this module, is designed to meet high reliability and fault tolerance standards.
• Environmental Conditions:
  • Operating Temperature: -20°C to 60°C (-4°F to 140°F)
  • Storage Temperature: -40°C to 85°C (-40°F to 185°F)
  • Humidity: 5% to 95% relative humidity (non-condensing).
• Safety Certifications:
  • CE, UL, CSA, and other certifications for use in hazardous environments and industries requiring rigorous safety standards.

Product Use:

The TRICONEX 3625C1 module is primarily used in industrial process control and safety applications. It is commonly deployed in systems that require high availability, redundancy, and fault tolerance for safety-critical operations. Some typical applications include:

1. Emergency Shutdown Systems (ESD):
   • Monitoring critical parameters to trigger emergency shutdowns when required.
2. Fire and Gas Detection Systems:
   • Detecting unsafe conditions in hazardous environments and triggering appropriate safety measures.
3. Process Safety Systems:
   • Managing the safety of industrial processes such as pressure, temperature, flow, or level monitoring.
4. Alarm and Shutdown Systems:
   • Ensuring that appropriate alarms and shutdown actions are taken when parameters exceed safe limits.
5. Plant Safety Monitoring:
   • Gathering data from sensors and field devices to monitor and control safety-critical processes in real time.

Key Benefits of the TRICONEX 3625C1:

• Redundancy: Provides a fault-tolerant design, ensuring high availability and reliability.
• Safety: Designed for high safety integrity, meeting stringent industrial safety standards such as IEC 61508 and IEC 61511.
• Scalability: Can be integrated into large systems, allowing for customized configuration based on process requirements.
• Real-time Processing: Supports real-time monitoring and control, making it suitable for mission-critical applications.
