Description

The Toshiba TCPSV module is part of Toshiba’s range of power semiconductor devices.

Product Name

• Toshiba TCPSV Module

Product Description

The TCPSV module is a type of power semiconductor used in various applications, including inverters, motor drives, and power control systems. It typically integrates high-speed switching capabilities with excellent thermal performance, making it suitable for demanding power applications.

Product Parameters

• Voltage Rating: Typically available in several voltage ratings suitable for high-voltage applications (e.g., 600V, 1200V).
• Current Rating: Varies by model; commonly rated for several hundreds of amps.
• Package Type: Can vary; often housed in compact, thermally efficient packages.
• Switching Frequency: Suitable for high-frequency operation, often designed for efficiency in PWM applications.

Specifications

• Electrical Characteristics:
  • Breakdown Voltage
  • Continuous Collector Current
  • Switching Losses
  • Thermal Resistance
• Thermal Characteristics:
  • Maximum Junction Temperature
  • Thermal Resistance (junction-to-case, junction-to-ambient)
• Mechanical Characteristics:
  • Dimensions (for physical integration)
  • Weight

Product Use

The TCPSV module is utilized in:

• Inverters: For converting DC to AC power in renewable energy systems (e.g., solar inverters).
• Motor Drives: For controlling electric motors in various industrial applications.
• Power Supplies: In both industrial and consumer electronics for efficient power regulation.
• Electric Vehicles: As part of the powertrain for electric and hybrid vehicles.
