ROCKWELL AUTOMATION+56AMXN

Description

The product name of the ROCKWELL AUTOMATION+56AMXNDCS PLC module is the ControlLogix 1756-AMXNDCS analog mixed module. The module is designed to provide mixed voltage and current analog I/O in a single module, making it a versatile solution for various automation applications.

Product Description:

The ControlLogix 1756-AMXNDCS module features 8 analog input channels and 4 analog output channels, supporting both voltage and current signals. It also includes a built-in RTD temperature sensor for monitoring temperature inputs.

Product Parameters:

– Number of analog input channels: 8
– Number of analog output channels: 4
– Input type: Voltage and current
– Output type: Voltage and current
– Temperature sensor type: RTD
– Communication protocol: EtherNet/IP

Specifications:

– Voltage Range: +/-10V
– Current Range: +/-20mA
– Resolution: 16-bit
– Update Time: 1 ms
– Operating Temperature: 0 to 60 degrees Celsius
– Power Consumption: 1.0A @5V

Product Use:

The ControlLogix 1756-AMXNDCS module is commonly used in industrial automation and control systems where analog I/O signals need to be interfaced with a Programmable Logic Controller (PLC). It is suitable for applications such as process control, monitoring, and data acquisition where precise control and monitoring of analog signals are required.
