ProSoft+MVI69E-MBTCP

Description

The ProSoft Technology MVI69E-MBTCP module is designed for interfacing between Modbus TCP networks and Rockwell Automation’s ControlLogix systems.

Product Name:

ProSoft MVI69E-MBTCP

Product Description:

The MVI69E-MBTCP module is a dual-port, Modbus TCP communication module for the Allen-Bradley ControlLogix platform. This module enables the ControlLogix processor to communicate with Modbus TCP devices, providing seamless integration between a wide range of Modbus-capable equipment and ControlLogix-based control systems. The MVI69E-MBTCP supports both Modbus Master and Slave functionalities, which allows it to either send requests to or respond to requests from other Modbus devices on the network.

Product Parameters:

• Protocol: Modbus TCP
• Number of Connections: Supports multiple concurrent Modbus connections.
• Communication Ports: Dual Ethernet ports for redundancy and network traffic management.
• Configuration: User-friendly configuration through ProSoft Configuration Builder software.
• Data Handling: Offers extensive data handling capabilities to read from/write to registers of connected Modbus devices.

Specifications:

• Power Supply: Operates on a standard ControlLogix 24V DC backplane power supply.
• Dimensions: Typically fits within a standard ControlLogix rack, maintaining compatibility with other modules.
• Temperature Range: Designed to work in varying environmental conditions (usually -20 to +70 degrees Celsius).
• Compatibility: Compatible with various versions of ControlLogix and Logix Designer software.
• Status Indicators: LED indicators for status and communication activity.

Product Use:

The MVI69E-MBTCP module is typically used in industrial automation applications where it is necessary to interface with numerous Modbus TCP devices, such as:

• SCADA systems
• IoT applications
• Plant floor machinery
• Energy management systems
• Building automation systems
