PROSOFT+MVI56E-MCM MVI56E-MNET

Description

The MVI56E-MNET module is a product from ProSoft Technology, designed for integrating Modbus TCP/IP communication into Rockwell Automation’s ControlLogix systems.

Product Name:

PROSOFT+MVI56E-MCM MVI56E-MNET – Modbus TCP/IP Communication Module for ControlLogix

Product Description:

The MVI56E-MNET module is a communication interface that allows ControlLogix processors to communicate with Modbus TCP/IP devices. This module supports both Modbus Master and Slave configurations, enabling two-way communication with a variety of Modbus-compatible devices. The MVI56E family of modules provides high-performance networking solutions for integration with existing Modbus systems or devices.

Product Parameters:

• Communication Protocol: Modbus TCP/IP
• Supported Communication Modes: Modbus Master/Slave
• Maximum Connections: Up to 32 simultaneous TCP connections
• Data Capacity: Number of registers supported (depends on configuration)
• Network Interface: Ethernet 10/100 Mbps
• Configuration: Web-based configuration interface for easy setup and management

Specifications:

• Power Supply: Typically powered from ControlLogix rack or external source, depending on the installation
• Operating Temperature: 0 to 60 degrees Celsius (32 to 140 degrees Fahrenheit)
• Storage Temperature: -40 to 85 degrees Celsius (-40 to 185 degrees Fahrenheit)
• Dimensions: Standard module dimensions (varies based on version)
• Mounting: Designed to fit into ControlLogix modular rack systems
• LED Indicators: Status and communication indicators for real-time diagnostics

Product Use:

• Industrial Automation: Integrating Modbus TCP/IP devices such as sensors, actuators, and PLCs into a ControlLogix architecture to streamline industrial processes.
• Data Acquisition: Collecting data from Modbus devices for monitoring, control, and SCADA systems.
• Migration Projects: Modernizing existing Modbus systems by connecting legacy devices to a modern ControlLogix platform.
• Interconnectivity: Facilitating communication between different protocols in a mixed protocol environment, enhancing system interoperability.
