PIONEER MAGNETICS+PM3398B-6-1-3-E

Description

The Pioneer Magnetics PM3398B-6-1-3-E controller is a high-performance power supply controller, typically used in industrial applications.

Product Name:

Pioneer Magnetics PM3398B-6-1-3-E Controller

Product Description:

The PM3398B-6-1-3-E is part of the Pioneer Magnetics line of high-efficiency power conversion and control systems. It is designed to provide reliable and flexible power management solutions for various industrial, telecommunications, and aerospace applications. This controller is engineered for managing the power flow to devices requiring precise voltage and current control, while ensuring high performance and low energy loss.

Product Parameters:

• Input Voltage: Typically supports a wide range of input voltages, such as 85–264 VAC or 36–72 VDC, depending on the specific model and configuration.
• Output Power: The controller is capable of outputting up to several kilowatts, with specific ratings depending on the configuration (such as 1.5 kW, 3 kW, or higher).
• Operating Frequency: It operates at a switching frequency of typically around 100 kHz, though this can vary depending on load conditions and model specifications.
• Control Mode: Likely uses advanced control algorithms such as PWM (Pulse Width Modulation) for voltage regulation and power efficiency.

Specifications:

• Input Voltage Range: 85-264 V AC or 36-72 V DC
• Output Voltage: Typically 5 V, 12 V, 24 V, or 48 V DC (depending on configuration)
• Output Power: Up to 3 kW or higher
• Efficiency: High efficiency (up to 95%) depending on the load and operating conditions.
• Temperature Range: Usually operates in a wide temperature range, such as -10°C to 70°C, with additional options for extended temperature ranges in harsh environments.
• Cooling: Typically fan-cooled or with integrated heat sinks for optimal thermal management.
• Regulation: Output voltage and current regulation to ensure stable power delivery even under fluctuating load conditions.
• Protection Features: Includes overvoltage, overcurrent, and thermal shutdown protection, ensuring safe and reliable operation.
• Size: Generally compact, designed for easy integration into equipment racks or enclosures.
• Compliance: Meets international standards for electromagnetic compatibility (EMC) and safety, such as UL, CE, RoHS, etc.

Product Use:

The PM3398B-6-1-3-E controller is typically used in applications that require reliable, high-efficiency power delivery. Some typical use cases include:

1. Telecommunications: Powering base stations, communication equipment, and networking hardware.
2. Industrial Automation: Providing power to control systems, motor drives, and other equipment.
3. Aerospace: Powering avionics systems, satellite equipment, and other mission-critical electronics.
4. Medical Equipment: Providing stable power for diagnostic machines, imaging devices, and other healthcare applications.
5. Test and Measurement: Used in laboratories or manufacturing facilities where precise power control is required for testing.

PIONEER MAGNETICS+PM3398B-6-1-3-E
