NI+SCXI-1324

Description

The NI SCXI-1324 is a module from National Instruments designed for use with the SCXI (Signal Conditioning eXtensions for Instrumentation) system.

Product Name

NI SCXI-1324

Product Description

The NI SCXI-1324 is a signal conditioning module that features multiplexed analog input channels specifically designed to convert and condition signals from a variety of sensors. This module provides essential features such as amplification, filtering, and signal isolation, making it suitable for a wide range of measurement applications.

Product Parameters and Specifications

• Number of Channels: 16 single-ended (or 8 differential) analog inputs.
• Input Range: Configurable ranges typically from ±10 V, ±5 V, ±1 V, etc.
• Gain: Programmable gain options for signal amplification.
• Input Impedance: High input impedance to minimize the loading effect on the sensor.
• Data Rate: Supports various rates depending on the configuration and connected DAQ hardware.
• Isolation: Offers signal isolation to protect the measurement system from high voltage or noise.
• Connection Type: Typically connects using SCXI bus, which may include integration with other SCXI modules.

Product Use

The NI SCXI-1324 is commonly used in:

• Data Acquisition Systems: For applications requiring the measurement of voltage signals from transducers, sensors, etc.
• Industrial Automation: To monitor and control processes through sensor data acquisition.
• Laboratory Research: For experimental setups where precise measurement and conditioning of signals are required.
• Environmental Monitoring: To measure variables such as temperature, pressure, and others from various sensor types.

Typical Applications

• Testing and monitoring of electronic devices.
• Structural health monitoring with strain gauges.
• Automotive testing, such as monitoring engine parameters.
• Any application where high-channel-count voltage measurement is necessary.

NI+SCXI-1324
