NI SCXI-1193

Description

The NI SCXI-1193 is a high-voltage general-purpose relay module offered by National Instruments (NI) as part of their SCXI (Signal Conditioning eXtensions for Instrumentation) platform.

– **Product Name:**

NI SCXI-1193 Relay Module

– **Product Description:**

The NI SCXI-1193 is a relay module designed for switching high voltages and currents in automated test systems. It provides a simple way to control external devices or signals using a SCXI system.

– **Product Parameters/Specifications:**

– Relay Type: SPST (Single-Pole Single-Throw)
– Maximum Switching Voltage: Typically up to 200 VDC/200 VAC
– Maximum Switching Current: Up to 2 A resistive load
– Channels: 8 relay channels
– Connector Type: 62-pin DSUB connector
– SCXI Compatibility: Works with National Instruments SCXI chassis

– **Product Use:**

The NI SCXI-1193 module is typically used in applications where automated switching of high voltage signals or control of external devices is required. It can be integrated into automated test systems alongside other SCXI modules to provide flexible signal conditioning and control capabilities.
