MTL+8715-CA-BI

Description

Product Name:

MTL+8715-CA-BI Module

Product Description:

The MTL+8715-CA-BI module is a highly reliable and efficient component designed for use in industrial automation and control systems. It serves as an interface module that enables seamless communication between field devices and control systems, providing essential features such as signal isolation, conversion, and amplification. The module is suitable for a variety of applications in process control, manufacturing, and other industrial environments where safety and performance are critical.

Product Parameters:

Type: Industrial Interface Module
Signal Type: Analog and Digital
Input/Output Configuration: Configurable channels
Isolation: 2.5kV isolation between field and control side
Power Supply Voltage: 24V DC
Current Consumption: ≤ 100mA
Operating Temperature: -40°C to +70°C
Dimensions: 100mm x 22.5mm x 110mm
Mounting Type: DIN rail mountable

Specifications:

Input Range: 0-10V, 4-20mA (configurable)
Output Range: 0-10V, 4-20mA (configurable)
Accuracy: ±0.1% of full scale
Response Time: ≤ 10ms
Communication Protocols: Modbus RTU, RS485
Environmental Protection: IP20
Weight: 150g

Product Use:

The MTL+8715-CA-BI module is primarily used in various industrial applications where reliable data acquisition and control are necessary. Some common use cases include:
Connecting sensors and actuators to control systems in manufacturing processes.
Providing signal isolation to protect control systems from field device anomalies.
Converting signals between different formats (e.g., from analog to digital) for compatibility with various control systems.

Enabling communication in a distributed control system (DCS) setup through protocols like Modbus

This module enhances the safety, efficiency, and reliability of process control systems, making it a vital component in industrial automation.
