MOTOROLA+MVME5500

Description

The MOTOROLA MVME5500 is a high-performance, rugged, and versatile embedded computer module designed for use in demanding industrial, military, and commercial applications. It was developed by Motorola, which later became part of the company now known as NXP Semiconductors. The MVME5500 is part of Motorola’s VMEbus-based product family, specifically optimized for real-time and mission-critical systems.

Product Name:

MOTOROLA MVME5500

Product Description:

The MVME5500 is a high-end embedded computer designed for use in systems that require robust performance, reliability, and expandability. It is based on a PowerPC architecture, which offers excellent computational capabilities while maintaining energy efficiency. The MVME5500 is designed for applications such as embedded control, industrial automation, and military systems, where high throughput, real-time performance, and fault tolerance are essential.

This module features a VMEbus (Versa Module Europa) architecture, allowing it to be used in systems that require high-speed data transfer between processors, I/O devices, and other peripherals. It provides flexibility with expansion options and a range of I/O interfaces suitable for industrial-grade environments.

Product Specifications & Parameters:

1. Processor:
   • Type: PowerPC 7447A (or equivalent)
   • Clock Speed: Up to 1.0 GHz
   • Cores: Single core (varies based on model/configuration)
2. Memory:
   • RAM: Up to 1 GB DDR SDRAM (on-board)
   • Non-volatile memory: Flash storage (typically 128 MB or 256 MB)
   • Expandable: Through the use of VMEbus peripherals
3. Bus Interface:
   • VMEbus: 6U VME (Versa Module Europa) form factor
   • VME64x: Supports VME64x bus standard, which allows for higher bandwidth (up to 320 MB/s)
   • PCIe (optional in some configurations): For additional high-speed I/O capabilities
4. I/O Ports:
   • Ethernet Ports: Typically 2x 10/100/1000 Mbps Ethernet ports (GbE)
   • Serial Ports: Multiple RS-232/RS-422 serial ports (typically 2 to 4)
   • USB Ports: 2x USB 2.0
   • Graphics Output: VGA or DVI (varies by configuration)
5. Expansion Slots:
   • Multiple VMEbus slots for I/O cards and peripheral modules
   • Optional PMC (PCI Mezzanine Card) slots for additional expansion
6. Video Output:
   • Graphics Interface: Onboard video controller (VGA, optionally DVI)
7. Power Supply:
   • Input Voltage: 5V DC
   • Power Consumption: Typically around 25-35 W (depending on configuration)
8. Operating System Support:
   • Linux, VxWorks, and other real-time operating systems (RTOS)
   • Support for standard embedded software development tools
9. Other Features:
   • Watchdog timer for fault detection
   • Temperature monitoring sensors
   • Optional hardware security features (encryption, secure boot)

Product Use:

The MOTOROLA MVME5500 module is used in various mission-critical and industrial applications. Some of the primary use cases include:

1. Industrial Automation:
   • The MVME5500 can be used in industrial control systems that require high reliability and real-time performance for managing manufacturing processes, robotics, and machine control.
2. Embedded Systems:
   • It’s well-suited for embedded applications in both civilian and military environments, where the robustness of VMEbus architecture and the PowerPC processor are required for system integration.
3. Aerospace & Defense:
   • The module is used in military applications such as avionics, radar systems, communication systems, and defense technology. Its rugged design allows it to function in harsh environments.
4. Communication Infrastructure:
   • It can be used in telecom base stations or network routers/switches, where high availability and fault tolerance are critical.
5. Real-Time Systems:
   • The MVME5500 is often used in systems where real-time performance is paramount, such as scientific instrumentation, medical devices, or process control.
6. Automated Test Equipment (ATE):
   • The module is widely used in automated test systems due to its high-performance computing and flexible I/O capabilities.

MOTOROLA+MVME5500
