Description

Product Name:

Motorola MVME162-213 (or MVME162-213)

Product Description:

The Motorola MVME162-213 is a single-board computer (SBC) based on the Motorola 68k family of processors. It is part of the MVME162 series, typically used in embedded computing applications requiring rugged and reliable performance in industrial, military, telecommunications, and other mission-critical environments. The MVME162-213 model features a 68020 or 68030 CPU (depending on the configuration) and offers various I/O interfaces, a versatile memory configuration, and support for VMEbus systems.

The MVME162-213 is particularly designed to work with VME-based systems, offering high-performance processing power in a compact and modular form factor. These boards often feature integrated components like memory, graphics, and networking capabilities, making them ideal for both stand-alone and networked embedded applications.

Product Parameters & Specifications:

1. CPU:
   • Processor: Motorola 68030 or 68020, 32-bit CPU
   • Clock Speed: Typically 25 MHz (may vary based on specific configurations)
   • Co-Processor: Optional 68882 (FPU) for floating-point operations
2. Memory:
   • On-board DRAM: 4 MB to 64 MB (depending on configuration)
   • SRAM: 128 KB to 512 KB (optional)
   • Flash/ROM Memory: Typically 1 MB (may vary)
   • Memory Configuration: Configurable for specific applications
3. Bus Interface:
   • VMEbus Interface: Standard VME 64-bit data bus
   • VMEbus: VME64 (6U form factor, 3U optional)
   • VMEbus Compatibility: Supports VME64 (IEEE 1014-1987 standard)
   • Slot Compatibility: 6U VME form factor (may differ in certain versions)
4. Input/Output:
   • Ethernet: 10Base-T / 100Base-TX (depending on model)
   • Serial Ports: 2 to 4 RS-232/RS-422
   • Parallel I/O: Supported through VMEbus
   • SCSI Interface: Optional (for specific configurations)
   • A/D & D/A: Optional, depending on I/O board configurations
5. Expansion:
   • Expansion Slots: Multiple (depending on exact version of MVME162-213)
   • Supports additional I/O boards, custom expansion, and peripherals through VME.
6. Operating System:
   • Supported OS: UNIX (typically VxWorks, Linux, and other embedded real-time operating systems)
   • Software Support: Full support for development environments and application libraries.
7. Power Supply:
   • Power Requirements: Typically 5V ±5% (some models may also support 3.3V for certain components)
   • Power Consumption: Varies depending on installed components (typically 20-30W)
8. Size/Dimensions:
   • Form Factor: 6U VME (approx. 160 mm x 233 mm) or 3U depending on specific model.
   • Weight: Approximately 0.5-1.0 kg (varies by configuration)
9. Cooling:
   • Heat Dissipation: Designed for industrial and harsh environments, passive cooling methods are typically used, with possible active cooling in higher-performance configurations.

Product Use:

The MVME162-213 module is used in a variety of applications across industries that require high performance in embedded systems, rugged computing environments, or mission-critical operations. Some typical uses include:

• Industrial Control Systems: Integrated into factory automation, robotics, and other control systems requiring high uptime.
• Telecommunications: Used in base stations, network routing, and switching equipment for robust performance.
• Defense & Aerospace: Deployed in embedded systems for military applications, radar, and communications platforms.
• Medical Devices: Can be utilized in diagnostics equipment or in systems requiring embedded computation.
• Research & Development: Ideal for research labs and scientific instruments requiring high-performance, real-time computing.

The MVME162-213 is especially suitable for embedded applications requiring VMEbus architecture, as it provides compatibility with a wide range of industrial and communication peripherals.
