MOTOROLA+MVME162-213

Description

The MOTOROLA MVME162-213 is a model of embedded computer board or module designed for use in industrial, military, and commercial applications where rugged computing power is needed. This board is part of the MVME series, which was popular for use in embedded systems, including telecommunications, automation, defense, and aerospace applications.

Product Name:

MOTOROLA MVME162-213

Product Description:

The MVME162-213 is a VMEbus-based single-board computer that integrates a microprocessor, memory, and peripheral interfaces into a single form factor. The MVME162 series is based on the Motorola 68k (Motorola 680×0) family of processors, which were widely used in embedded systems during the 1990s. The MVME162-213 model specifically offers robust performance, expanded I/O capabilities, and high reliability for demanding applications. It includes features such as onboard memory, communication ports, and support for various expansion options.

Product Parameters and Specifications:

1. Processor:
   • Processor Type: Motorola 68020 (or compatible) processor
   • Clock Speed: 25 MHz
   • Processor Architecture: 32-bit
   • Floating Point Unit (FPU): Optional, depending on specific configurations
2. Memory:
   • RAM: Typically 4 MB to 16 MB of onboard DRAM (configurable)
   • EPROM/Flash ROM: 256 KB or more for storing firmware and boot code
   • Expandable Memory: The system can support additional memory modules through the VMEbus interface.
3. I/O and Communication Ports:
   • VMEbus Interface: Full VME (Versa Module Europa) bus support, which allows communication with other VME-based systems and expansion cards.
   • Serial Ports: Usually provides multiple RS-232/RS-422/RS-485 serial ports for communication.
   • Parallel I/O Ports: Used for connecting various peripheral devices.
   • Ethernet: Typically supports 10Base-T or 100Base-T Ethernet interfaces for network connectivity.
   • SCSI/ATA: May support hard drive or disk interfaces through standard connectors.
   • Other I/O Interfaces: Depending on the configuration, it may have other interfaces such as parallel, ADC, or additional expansion ports.
4. Expansion:
   • VME Slots: The board can interface with other VMEbus expansion cards for additional functionality, such as additional memory, network cards, or custom I/O modules.
5. Power Supply:
   • The board typically operates with a standard power supply input (e.g., +5V DC), with provisions for higher voltage inputs depending on the configuration.
6. Software Support:
   • The MVME162 typically supports real-time operating systems (RTOS) such as VxWorks, QNX, or custom OS for embedded systems.
   • It may also support standard UNIX-based operating systems, including Linux, depending on software compatibility.
7. Form Factor:
   • Board Type: 6U VME (Dimensions: typically 6.30 inches x 12.30 inches or 160 mm x 310 mm, depending on model configuration)
   • Mounting: Designed for installation into a VME chassis.
8. Operating Conditions:
   • Temperature Range: Typically operates within a -40°C to +85°C range for industrial and military applications.
   • Environmental Compliance: The board is designed to meet rugged, MIL-SPEC standards for shock, vibration, and environmental conditions.

Product Use:

The MOTOROLA MVME162-213 is used primarily in embedded systems where real-time computing, high reliability, and long-term operational stability are essential. Common use cases include:

• Industrial Control Systems: Used in factory automation and control systems where reliable computing and real-time performance are critical.
• Telecommunications: Used in network routers, base stations, and communication infrastructure.
• Military and Aerospace Applications: Due to its rugged design, the MVME162 series is often used in avionics, defense equipment, and other applications that require high performance in harsh environments.
• Medical Equipment: It can be found in medical devices that require embedded computing, data collection, and analysis.
• Robotics: Used in robotics systems where processing power and peripheral communication capabilities are needed.

MOTOROLA+MVME162-213
