Description

The MOTOROLA MCP750 module is a powerful embedded microprocessor module designed primarily for industrial, telecommunications, and other embedded system applications. It is based on the Motorola 750 microprocessor, which is a part of the PowerPC architecture.

Product Name:

MOTOROLA MCP750 Module

Product Description:

The MOTOROLA MCP750 module is a compact, high-performance embedded computing platform that integrates the Motorola PowerPC 750 microprocessor. This module provides users with a flexible, cost-effective solution for high-speed, low-power applications, featuring robust processing power, reliability, and scalability. It is designed for a variety of industrial, networking, and telecommunications applications, offering strong support for embedded systems development.

The MCP750 module typically includes the core PowerPC 750 processor, memory options, I/O ports, and connectivity features, making it suitable for integration into embedded products requiring advanced computing power and energy efficiency.

Product Parameters:

• Processor: PowerPC 750 (or equivalent)
• Clock Speed: Typically 200 MHz to 400 MHz
• Processor Cores: Single core
• Instruction Set: PowerPC (32-bit/64-bit)
• Memory:
  • Onboard DRAM: 64 MB to 256 MB (depending on the configuration)
  • Flash Storage: 8 MB to 32 MB
  • External memory options supported via memory interfaces (e.g., SDRAM, Flash, etc.)
• I/O Ports:
  • Ethernet ports (10/100/1000 Mbps)
  • Serial ports (RS232/RS485)
  • USB 1.1/2.0 (optional)
  • Parallel port or PCI bus interface (varies by specific model)
  • GPIO (General Purpose Input/Output)
• Connectivity:
  • UART (Universal Asynchronous Receiver/Transmitter)
  • SPI (Serial Peripheral Interface)
  • I2C (Inter-Integrated Circuit)
• Form Factor: Typically in a compact embedded module form (e.g., PC/104, DIMM, or proprietary form)
• Operating Voltage: 3.3V or 5V depending on the configuration
• Power Consumption: Typically in the range of 5W – 10W (depending on usage and clock speed)

Product Specifications:

1. Processor:
   • Motorola PowerPC 750 microprocessor
   • Clock speed: 200 MHz to 400 MHz
   • FPU (Floating Point Unit) for efficient numerical calculations
   • 32-bit architecture with a 64-bit memory address space
2. Memory:
   • DRAM: 64MB to 256MB
   • Flash Memory: 8MB to 32MB (non-volatile storage)
3. Interfaces:
   • Ethernet (10/100/1000 Mbps)
   • Serial ports: RS-232, RS-485
   • USB 1.1/2.0 ports (depending on module version)
   • I2C, SPI, and GPIO for sensor or peripheral connectivity
4. Operating Environment:
   • Operating temperature: 0°C to 70°C (commercial-grade)
   • Storage temperature: -40°C to 85°C (industrial-grade options)
   • Humidity: 10% to 90% non-condensing
5. Power Supply:
   • Operating voltage: 3.3V or 5V (depending on configuration)
   • Power consumption: 5W to 10W
6. Software Support:
   • Compatible with embedded OS like Linux, VxWorks, or custom real-time operating systems (RTOS)
   • Supports development environments such as Eclipse or CodeWarrior
7. Connectivity:
   • 10/100/1000 Ethernet (for networked applications)
   • USB (for peripheral device support)
   • Serial (for communication with legacy equipment)

Product Use:

The MOTOROLA MCP750 module is primarily used in embedded system applications where high processing power, energy efficiency, and compact form factor are required. Typical use cases include:

1. Industrial Automation:
   • Control and monitoring systems for manufacturing equipment and processes
   • Robotics and intelligent automation
   • SCADA (Supervisory Control and Data Acquisition) systems
2. Telecommunications:
   • Network routers, switches, and embedded networking hardware
   • Gateways for communication systems
3. Medical Equipment:
   • Diagnostic devices and medical data processing
4. Consumer Electronics:
   • Embedded systems for consumer devices that require high-speed processing and low power
5. Military and Aerospace:
   • Embedded computing for rugged, mission-critical applications
   • Flight control systems and unmanned aerial vehicles (UAVs)
6. Automotive:
   • Advanced driver-assistance systems (ADAS)
   • In-vehicle infotainment and navigation systems
