HONEYWELL+CC-PAIX01

Description

Product Name:

Honeywell CC-PAIX01 Analog Input Module

Product Description:

The Honeywell CC-PAIX01 module is an analog input module designed for use in Honeywell control systems. It allows for the integration of analog signals from various field devices into the control system for monitoring and control purposes.

Product Parameters:

– Input Channels: 8 differential analog input channels
– Input Type: Voltage or current
– Input Range: Configurable per channel
– Resolution: 16-bit
– Update Rate: Configurable
– Isolation: 500V RMS between channels and bus
– Communication: Profibus DP communication protocol

Specifications:

– Operating Temperature: -40°C to 70°C
– Storage Temperature: -40°C to 85°C
– Power Supply: 24V DC
– Dimensions: 138mm x 128mm x 77mm
– Weight: 500g

Product Use:

The Honeywell CC-PAIX01 module is used in various industrial applications where analog signals need to be monitored and controlled. It is commonly used in process control systems, distributed control systems, and other industrial automation applications. The module allows for precise monitoring of analog inputs such as temperature, pressure, level, flow, and other process variables, helping improve the overall efficiency and control of industrial processes.
