HONEYWELL+8C-PCNT02

Description

The Honeywell 8C-PCNT02 is a digital counter module used in industrial automation applications. It’s designed to manage and process counting signals, typically from sensors or pulse-generating devices.

Product Name:

Honeywell 8C-PCNT02 Digital Counter Module

Product Description:

The Honeywell 8C-PCNT02 module is designed to receive pulse input signals and perform counting operations in real-time. It typically interfaces with control systems like Programmable Logic Controllers (PLCs) or Distributed Control Systems (DCS), enabling automation systems to monitor events, cycles, or throughput. The counter module may be used in applications that require pulse accumulation, event detection, and totalization, such as machine counting, flow measurement, or process monitoring.

This module is part of Honeywell’s family of industrial controllers and input/output (I/O) systems, and it is engineered for high reliability, precision, and ease of integration with Honeywell’s automation and control systems.

Product Parameters:

• Input Type: Pulse input (digital)
• Input Voltage Range: Typically 24V DC (depending on model configuration)
• Counter Type: Digital or programmable
• Counting Speed: Dependent on the specific application and pulse frequency
• Number of Inputs: Depending on model configuration, it may support one or multiple input channels.
• Display: Usually includes indicators for count values (may require external displays in certain configurations).
• Operating Temperature Range: Typically -20°C to 60°C (-4°F to 140°F)
• Power Supply: 24V DC (typically)
• Communication Protocols: May be designed to work with proprietary communication protocols for integration with other Honeywell control systems.
• Mounting: DIN rail or panel mount depending on configuration.

Specifications:

• Digital Input Characteristics:
  • Active pulse input (high or low)
  • Trigger level and debounce filtering to handle noisy signals
  • Maximum input frequency (varies by model)
• Counters:
  • Number of counts: Typically configurable, supports both up and down counting modes
  • Preset values: Allows setting a target count value for event triggering or alarms
• Relay Outputs: May have relay outputs to signal when certain thresholds or counts are reached.
• Environment: Designed for use in industrial environments, rugged and resistant to temperature and electrical noise variations.
• Isolation: May feature galvanic isolation between inputs and outputs to protect against electrical surges.
• Protection: Overvoltage, overcurrent, and reverse polarity protection.

Product Use:

The Honeywell 8C-PCNT02 counter module is used in a variety of industrial automation applications such as:

• Machine Counting: For monitoring the number of cycles or units produced on manufacturing lines.
• Flow Measurement: Counting pulses from flow meters to track volume or mass flow in pipelines.
• Event Detection: Monitoring events in industrial processes, like detecting machine operations or machine failure events.
• Totalization: Accumulating counts from multiple sources over time for reporting or triggering actions at set thresholds.
• Batch Processing: Counting materials or products processed through a system in batch operations.
• Control Systems Integration: Interface with PLCs, SCADA systems, or DCS for process monitoring, control, and automation.

Typical Applications:

• Manufacturing: Monitoring production counts, cycle times, and machine performance.
• Oil & Gas: Tracking fluid movement in pipelines, gas flow, and other process parameters.
• Water Treatment: Counting water flow rates or cycles in treatment plants.
• Food & Beverage: Tracking unit production, filling cycles, and other manufacturing processes.
• Automotive & Aerospace: Monitoring parts or assembly operations in a production line.

HONEYWELL+8C-PCNT02
