HIMA+F3 AIO 8/4 01

Description

Product Name:

HIMA+F3 AIO 8/4 01 Module

Product Description:

The HIMA+F3 AIO 8/4 01 module is an advanced I/O module designed for use in industrial automation and safety-critical applications. This module typically integrates with a HIMA safety system, offering both analog and digital input/output capabilities. It’s engineered to provide high performance, robust reliability, and flexibility in various industrial control environments.

The F3 AIO module is part of the HIMA F3 series, which is known for its use in safety and process control systems, offering high fault tolerance and diagnostic capabilities. This module is typically used in applications where critical safety processes must be monitored and controlled efficiently and with precision.

Product Parameters:

• Input/Output Configuration:
  • 8 Digital Inputs
  • 4 Analog Outputs
• Digital Input Type:
  • Dry contact (potential-free)
  • Voltage levels: 24V DC (common in industrial applications)
• Analog Output Type:
  • Voltage or Current (usually 0-10V DC, 4-20 mA)
• Communication Interface:
  • Compatible with HIMA safety controllers and PLCs
  • Typically uses fieldbus communication protocols such as PROFIBUS or Modbus (depending on the configuration)
• Power Supply:
  • Typically operates at 24V DC
• Response Time:
  • Typically < 10ms for digital inputs
  • Analog outputs may have a conversion time of 50-100ms
• Operating Temperature Range:
  • -20°C to +60°C (standard industrial temperature range)
• Protection Class:
  • IP20 (suitable for installation in control panels or cabinets)
• Mounting Type:
  • DIN rail mounted (common for industrial control modules)
• Diagnostics:
  • Built-in diagnostic features such as input/output status and fault detection
• Compliance:
  • Typically complies with IEC 61508 and IEC 61511 for functional safety
  • CE, UL certifications

Specifications:

• Module Type: AIO (Analog I/O)
• Total I/O Channels: 12 (8 digital, 4 analog)
• Signal Processing: Digital signal processing for inputs and DAC (Digital to Analog Conversion) for outputs
• Housing: Compact design suitable for installation in control cabinets
• Fault Tolerance: Features redundant safety mechanisms for error detection and fail-safe operation
• Diagnostic LEDs: Indicate operational status and any faults or warnings

Product Use:

The HIMA+F3 AIO 8/4 01 module is typically used in industrial control systems, particularly in applications requiring high safety standards such as:

1. Process Control: Managing and automating processes in chemical, oil & gas, and power plants.
2. Safety Instrumented Systems (SIS): Where functional safety is required, such as in emergency shutdown systems (ESD).
3. Machine Safety: Ensuring the safe operation of machinery and monitoring safety-critical sensors or actuators.
4. Monitoring and Control: Suitable for systems needing both analog and digital I/O to monitor variables like temperature, pressure, flow, etc., while maintaining high operational safety and system integrity.

HIMA+F3 AIO 8/4 01
