GE+SR469-P5-HI-A20-E

Description

Product Name:

GE SR469-P5-HI-A20-E

Product Description:

The GE SR469-P5-HI-A20-E is a protection and control relay designed for high-performance applications in electrical systems. This device is typically used in industries for motor protection, system diagnostics, and fault monitoring. It is part of the SR469 series from General Electric, offering a high level of functionality in protecting power generation and distribution equipment from electrical faults, abnormal conditions, and operational inefficiencies.

This relay is specifically tailored to work in environments where high voltage and current monitoring and protection are necessary, providing users with advanced diagnostic capabilities, clear visibility of system conditions, and reliable fault detection.

Product Parameters and Specifications:

• Input Voltage:
  Supports a wide input voltage range, typically 120/240V AC or 24V DC.
• Protection Types:
  • Overcurrent protection
  • Short-circuit protection
  • Ground fault detection
  • Under/Over voltage protection
  • Thermal overload protection
  • Phase loss and phase reversal protection
• Relay Configuration:
  • Digital and analog inputs and outputs
  • Programmable logic and settings
  • Up to 5 inputs for system configuration and fault detection
• Communication Interface:
  • Modbus RTU
  • Ethernet/IP (depending on model)
  • DNP3
• Display & Interface:
  • LCD or LED display for real-time monitoring
  • Buttons or keypad for local configuration and setup
• Dimensions:
  Typically compact (but can vary depending on exact model).
• Mounting:
  Designed for DIN rail or panel mounting depending on installation requirements.
• Power Consumption:
  Typically consumes between 5W and 15W depending on the configuration.
• Temperature Range:
  Operational temperature typically from -20°C to +60°C, suitable for industrial environments.
• Housing:
  Robust, flame-retardant plastic housing designed for industrial applications.
• Certification and Standards:
  Meets international standards such as IEC 60255, UL 508, and CE marking.

Product Use:

The GE SR469-P5-HI-A20-E controller is commonly used in the following applications:

1. Motor Protection:
   For protecting large motors in industrial plants, it provides protection against short circuits, overcurrents, and ground faults, ensuring motor reliability and longevity.
2. Power System Protection:
   It can be integrated into power distribution systems to safeguard electrical equipment from faults and voltage fluctuations.
3. Automation and Control Systems:
   It can be programmed for specific control tasks within automation systems, including logic operations, monitoring of processes, and fault management.
4. Renewable Energy Systems:
   In renewable energy plants such as wind farms or solar power facilities, the relay can help protect critical components like inverters and transformers.
5. Industrial Equipment Monitoring:
   With its advanced diagnostics and fault detection capabilities, it is ideal for use in industries that require constant monitoring and protection of critical equipment, such as petrochemical, water treatment, and manufacturing industries.

GE+SR469-P5-HI-A20-E
