GE+IS420UCSBH1A

Description

The GE IS420UCSBH1A module is part of the GE Speedtronic™ series used in gas turbine control systems, such as the GE Mark VIe or Mark VI. This module is typically a communication or I/O (input/output) module designed for interfacing between field devices and the control system.

Product Name:

• GE IS420UCSBH1A – UCSB High-Speed Bus Interface Module

Product Description:

The IS420UCSBH1A is a communication module used in GE’s gas turbine control systems, specifically designed to manage data exchanges between the controller and various peripheral components. It is part of the Mark VIe platform and enables high-speed communication across the system, facilitating real-time data processing, troubleshooting, and control functions.

This module ensures seamless communication between multiple units within the control system, enabling the optimization of turbine operation, real-time diagnostics, and maintenance capabilities. It is a crucial part of the control architecture for large industrial processes like power plants, refineries, and other critical infrastructure.

Product Parameters and Specifications:

1. Type:
   • Communication Interface Module
   • I/O Bus Interface (UCSB)
2. Functionality:
   • High-Speed communication interface
   • Data transfer between the control system and peripheral components
   • Real-time control and diagnostics
3. Compatibility:
   • GE Mark VIe control system or GE Speedtronic turbine control systems
   • Interfacing with I/O modules, communication devices, and field devices
4. Electrical Specifications:
   • Voltage Rating: Typically operates on 24 V DC, depending on the specific model and configuration
   • Current Consumption: Low power, typical for modules in this class
   • Signal Types: Digital/Analog I/O (depending on configuration)
5. Communication Protocol:
   • Uses UCSB (Universal Control and Signal Bus) for high-speed data transfer
   • Supports multiple bus-based data transmission standards
6. Mounting:
   • Typically mounted in a rack or chassis in the control panel
   • The module connects via DIN rail or other standard mounting setups used in industrial control systems
7. Dimensions:
   • 4U or 6U (standard rack unit size) depending on the control cabinet configuration
8. Environmental Conditions:
   • Operating temperature: 0°C to 60°C (32°F to 140°F)
   • Humidity: 5% to 95% (non-condensing)
   • Designed for use in industrial environments, which may include high vibration and electrical noise
9. Safety:
   • CE compliant
   • UL and other regional safety standards may apply depending on location and installation

Product Use:

• Turbine Control Systems: The IS420UCSBH1A is primarily used in gas turbine control systems where high-speed data exchange is crucial for managing real-time operations.
• Power Generation Plants: It helps to control various sensors, actuators, and field devices in power plants, ensuring safe and efficient turbine operations.
• Oil & Gas, Refineries, and Other Heavy Industries: The module’s robust design is suitable for critical infrastructure such as refineries, oil rigs, and industrial plants, where communication between control systems and operational equipment is essential.
• Real-time Diagnostics & Maintenance: The module enables continuous monitoring, fault detection, and diagnostic data reporting to optimize turbine performance and minimize downtime.

GE+IS420UCSBH1A
