GE+IS420ESWBH3A

Description

The GE IS420ESWBH3A is a specific module used in industrial control systems, typically within the context of GE’s Mark VIe or similar control systems, which are used for power generation, manufacturing, and other industrial automation applications.

Product Name:

GE IS420ESWBH3A – Ethernet Switch Module.

Product Description:

The IS420ESWBH3A is an Ethernet Switch Module used in GE’s control systems, such as the Mark VIe, to enable high-performance network communication between various control system components. It is designed for use in environments requiring robust, secure, and reliable network communication, such as industrial power plants, substations, and process control applications. The module typically supports multiple network ports and facilitates communication between different parts of the system, improving data exchange and redundancy.

Product Parameters and Specifications:

• Functionality:
  • Acts as an Ethernet switch, enabling communication between control systems and field devices.
  • Supports multiple Ethernet ports to ensure high-speed data transfer.
  • Provides network redundancy and failover to maintain system uptime and reliability.
• Ethernet Ports:
  • The module typically has multiple Ethernet ports for both primary and secondary network connections, supporting high-speed data communication.
• Redundancy:
  • Built-in redundancy features for ensuring that the system remains operational in the event of a network failure.
• Supported Protocols:
  • Generally, the module supports standard Ethernet communication protocols such as TCP/IP, UDP, and others commonly used in industrial control systems.
• Operating Temperature Range:
  • Typically ranges between 0°C to 60°C (32°F to 140°F), but this can vary slightly based on the specific environmental conditions and system configuration.
• Power Supply:
  • The module usually operates with the system’s standard DC power supply (24V DC or 48V DC).
• Physical Form Factor:
  • The IS420ESWBH3A module is designed as a rack-mounted unit, fitting into GE’s modular control system racks.
• Environmental Protection:
  • The module is designed to meet industrial-grade environmental standards for vibration, shock, and electromagnetic interference (EMI).

Product Use:

• Network Communication in Industrial Systems: The IS420ESWBH3A module is used to establish reliable communication between different components of a GE control system, such as controllers, input/output modules, and human-machine interfaces (HMIs).
• Redundant Network Configurations: It is used in systems where network uptime and redundancy are critical, such as in power plants and large-scale industrial automation systems.
• Data Transfer & Control: Facilitates high-speed data transfer between field devices (e.g., sensors, actuators) and the control system for real-time monitoring and control operations.
• Automation and Monitoring: Commonly found in systems that require continuous monitoring and automation of processes, ensuring that data is transferred seamlessly across the control network.

Applications:

• Power generation plants
• Oil and gas industry automation
• Industrial manufacturing processes
• Critical infrastructure systems requiring secure, redundant communication networks

This module plays a crucial role in ensuring that communication between various subsystems within the control system remains uninterrupted, reliable, and secure.
