GE+IS220TCATH1A

Description

The GE+IS220TCATH1A module is part of the General Electric (GE) Mark VIe control system, commonly used in industrial applications such as gas and steam turbine control.

Product Name

GE+IS220TCATH1A Module

Product Description

The IS220TCATH1A is an analog input module designed for the Mark VIe distributed control system. It facilitates the connection of various temperature sensors, enabling the monitoring and control of temperature across different processes in industrial systems.

Product Parameters / Specifications

• Input Type: Thermocouple and RTD (Resistance Temperature Detector) inputs.
• Input Range: Supports a wide range of thermocouple types (e.g., J, K, T, E, N, R, S, B).
• Resolution: High-resolution inputs for accurate temperature measurements.
• Number of Inputs: Typically supports multiple input channels for simultaneous monitoring.
• Calibration: Features built-in calibration options.
• Communication: Integrates with the Mark VIe control network for data reporting and system communication.
• Operating Temperature Range: Designed for harsh industrial environments.
• Power Supply Requirement: Requires connection to the control system’s power supply.

Product Use

The IS220TCATH1A module is used primarily in the following applications:

• Turbine Control: Monitoring temperature to ensure optimal performance and safety.
• Process Control: Managing thermal conditions in manufacturing and production processes.
• Safety Systems: Part of safety interlock systems to prevent overheating or malfunctioning equipment.

Additional Features

• Diagnostic Capabilities: Provides detailed diagnostics and status information for enhanced troubleshooting.
• Modular Design: Facilitates easy integration and replacement within the control system.
