GE+IS220PAICH1A

Description

The GE IS220PAICH1A module is part of the GE Mark VIe series of control systems. It is primarily used in industrial control and automation systems, especially in power generation and energy management systems.

Product Name:

GE IS220PAICH1A – Power Analog Input Channel (PAI)

Product Description:

The IS220PAICH1A is a Power Analog Input Channel module used in the GE Mark VIe control system. It is designed for analog input processing, providing precise measurements of physical signals (e.g., voltage, current, pressure, temperature) and converting them into a format suitable for digital processing within the control system.

The module is typically used for monitoring and control in systems like gas turbines, steam turbines, and other industrial machinery. It interfaces with a variety of sensors, providing data that can be used for process control, safety monitoring, and performance analysis.

Product Parameters:

• Module Type: Analog Input Channel
• Power Supply: Typically powered from the Mark VIe system
• Input Channels: Provides multiple channels for analog input signals
• Signal Conditioning: Includes features to condition analog signals (e.g., filtering, scaling, etc.)
• Signal Type Compatibility: Can handle standard industrial analog inputs (e.g., 4-20 mA, 0-10 V, thermocouples, RTDs)
• Isolation: Typically offers electrical isolation between the input and system for safety and noise reduction.

Specifications:

• Signal Types: 4-20 mA, 0-10 VDC, thermocouples, resistance temperature detectors (RTDs), and other industrial signal formats
• Input Range: Varies depending on the signal type and application
• Channel Count: The module typically supports multiple input channels (e.g., 8 or more channels depending on the configuration)
• Accuracy: High accuracy for precise monitoring and control
• Temperature Range: Designed to operate in industrial environments with a specified operating temperature range
• Isolation: Each input channel is typically isolated to prevent electrical interference
• Connector Type: Screw terminals, or sometimes D-shell connectors for ease of wiring and system integration
• Environmental Conditions: Designed to operate in industrial conditions with a wide operating temperature range and resistance to vibration and electrical noise.

Product Use:

• • Industrial Control Systems: Used in industries like power generation, chemical plants, and manufacturing for real-time monitoring of process variables (e.g., pressure, temperature, vibration).

• Power Generation: Specifically used in power plants to monitor various parameters of turbine performance, combustion processes, and generator operations.
• Condition Monitoring and Diagnostics: Provides data for system diagnostics, fault detection, and predictive maintenance by measuring key performance indicators of industrial equipment.
• Automation and Control: Interfaces with controllers and safety systems to automate industrial processes and improve operational efficiency and safety.

GE+IS220PAICH1A
