Description

The GE IS210MACCH1AKH module is a part of General Electric’s Mark VIe control system, which is used for process control in industrial applications such as power plants. This particular module is typically used as part of the system’s control and protection framework.

Product Name:

GE IS210MACCH1AKH – Mark VIe Controller Communication Module

Product Description:

The GE IS210MACCH1AKH module is designed for use within the GE Mark VIe control systems, often utilized in industrial automation environments, including turbine control, power generation, and other large-scale industrial operations. This module serves a critical function by managing communication between various components of the control system, such as controllers, sensors, and other field devices.

Product Parameters & Specifications:

1. Module Type:
   • Controller Communication Module (MAC)
   • Designed for Mark VIe control systems.
2. Communication Protocol:
   • Supports a variety of communication protocols, including Ethernet and serial communication, for seamless integration into the broader control network.
3. Input/Output (I/O):
   • The MACCH1AKH module interfaces with other control modules, sensors, and actuators, supporting both digital and analog I/O depending on the system configuration.
4. Power Supply:
   • Typically powered from the control system’s common power supply for consistency and reliability.
5. Dimensions:
   • The module generally fits within standard control cabinets or racks, designed to be compact and efficient.
6. Operating Temperature:
   • Typically designed to function in industrial environments, with an operational temperature range of 0°C to 60°C (32°F to 140°F).
7. Mounting:
   • Can be mounted on DIN rails or within specially designed enclosures that support the GE Mark VIe system.
8. Compatibility:
   • Fully compatible with GE’s Mark VIe control systems, ensuring smooth integration with other modules such as I/O units, controllers, and safety devices.
9. Redundancy and Reliability:
   • The IS210MACCH1AKH module supports redundant configurations to ensure high system availability, a key feature for mission-critical operations such as power generation.

Product Use:

The GE IS210MACCH1AKH module is primarily used in:

• Turbine and Power Plant Control Systems: Used to interface between different parts of the control system, facilitating communication and ensuring coordinated operation of critical equipment such as turbines, generators, and boilers.
• Industrial Automation: Can be used in a variety of industrial applications where real-time data exchange between controllers and remote devices is necessary.
• Process Control Systems: Often used in complex process control environments that require high reliability and continuous data exchange to maintain system stability and safety.
• Monitoring and Diagnostics: The module assists in system monitoring by communicating critical data regarding system performance and health, helping operators detect and respond to issues quickly.
