GE+IS200ERDDH1ABA

Description

The GE IS200ERDDH1ABA is a PLC module from the RX3i series.

Product Name:

GE Fanuc RX3i PLC Module, IS200ERDDH1ABA

Product Description:

The IS200ERDDH1ABA is a high-speed counter module that is part of the RX3i series. It provides advanced counting capabilities for a variety of industrial applications.

Product Parameters:

– Input Voltage: 12-24 VDC
– Input Current: 120 mA at 5 VDC
– Operating Temperature: 0 to 60°C
– Storage Temperature: -40 to 100°C
– Dimensions: 3.8 H x 1.35 W x 4.92 D

Specifications:

– The module features four high-speed input channels and supports both single-ended and differential inputs.
– It has a maximum input frequency of 500 kHz for all channels.
– The module provides latching and non-latching counter modes, as well as quadrature and up/down counter modes.

Product Use:

The IS200ERDDH1ABA module is used in industrial automation applications where precise high-speed counting and motion control are required. It is commonly used in packaging, material handling, and other high-speed production processes.
