GE+IS200DTAIH1ACC

Description

The GE IS200DTAIH1ACC module is part of General Electric’s (GE) industrial control and automation system components, typically used in turbine control and automation systems.

Product Name:

GE IS200DTAIH1ACC – Digital Turbine Automation Interface (DTAI) Module.

Product Description:

The IS200DTAIH1ACC is a module designed for use in GE’s turbine control systems, such as those in gas or steam turbines. It is typically used within the Mark VIe or similar turbine control systems. This module interfaces between digital turbine control systems and field devices, providing input and output capabilities, communication between control systems, and real-time monitoring of turbine operation.

It acts as a digital-to-analog interface, enabling seamless communication between the turbine’s control system and its field devices (sensors, actuators, and other critical hardware).

Product Parameters & Specifications:

• Product Type: Digital Turbine Automation Interface (DTAI) Module.
• Input/Output Configuration:
  • Digital Inputs: Handles digital signals, likely including status signals from turbine equipment.
  • Analog Inputs/Outputs: Interfaces with various field devices, sensors, and actuators.
  • Output Channels: Responsible for controlling actuators, valves, and other mechanical systems in the turbine.
• Power Supply: Typically operates at a voltage of 24V DC, but power requirements can vary based on configuration.
• Communication Protocol: Supports serial and ethernet protocols for communication with the central control system and other modules.
• Form Factor: Likely a compact, rack-mountable design that can easily integrate with other control modules in a turbine control system.
• Environmental Conditions:
  • Operating Temperature: Typically around 0°C to 60°C (depending on the application).
  • Humidity: Designed to operate in industrial environments, so it’s rated for high humidity conditions.
• Durability and Reliability: Designed for high-reliability applications in industrial environments, including turbines, power plants, and other critical systems.
• Redundancy: Can be part of a redundant system for high-availability applications, particularly in power generation.

Typical Product Uses:

• Turbine Control Systems: The IS200DTAIH1ACC is commonly used in turbine control systems, particularly in the Mark VIe turbine control platform, which is employed in gas, steam, and hydroelectric turbines.
• Process Control: Used for automating control systems in power generation plants, where precise control of turbine operation is essential for efficiency and safety.
• Monitoring and Diagnostics: Provides continuous real-time monitoring of turbine components, such as blades, rotors, and mechanical systems, which helps identify performance degradation or failures.
• Automation and Control: Acts as an interface to control valves, actuators, and other mechanical systems based on input from sensors and the control system.
• Integration in Industrial Automation: The IS200DTAIH1ACC is part of a larger industrial control system that includes sensors, alarms, and advanced diagnostic capabilities to ensure safe and efficient operation of turbines in critical infrastructure.
