GE+IS200AEPCH1BAA

Description

The GE IS200AEPCH1BAA module is a component used in General Electric (GE) control systems, particularly in industrial automation and power generation applications. It is part of GE’s Mark VIe series of control systems, which are widely used for turbine and generator control. This specific module is designed to provide electronic protection, control, and monitoring functions in a distributed control system (DCS).

Product Name:

• GE IS200AEPCH1BAA – Analog Output Module for Mark VIe system

Product Description:

The GE IS200AEPCH1BAA module is an analog output module that interfaces with the control system to manage the output of analog signals to connected devices. These signals can be used to control various parameters in a system, such as valve positions, actuator positions, or other equipment requiring analog control. The module is part of the Mark VIe integrated control system, designed for use in power generation, oil and gas, and other critical industrial environments.

This module typically features high-reliability, precision control, and easy integration within larger control systems. It is engineered to meet the demands of industries that require continuous uptime and precise monitoring/control of large, complex machinery such as turbines, generators, or industrial pumps.

Product Parameters:

• Module Type: Analog Output Module
• Part Number: IS200AEPCH1BAA
• Series: Mark VIe
• Function: Analog output to control various system components
• Input Signal Type: Digital control signals
• Output Signal Type: Analog output (typically 4-20mA or 0-10V, depending on configuration)
• Communication Interface: Supports the system’s communication protocols (e.g., Ethernet, serial, etc.)
• Power Supply Voltage: Typically 24V DC (depends on installation specifications)

Specifications:

• Input Voltage: 24V DC (nominal)
• Output Signal Range: 4-20 mA or 0-10 V (dependent on configuration)
• Current Consumption: Varies depending on output configuration and load
• Mounting Type: Standard rack-mounted or panel-mounted module
• Environment Temperature Range: Typically -40°C to 70°C
• Compliance Standards: Meets industrial control system standards (IEC, UL, etc.)
• Weight: Approx. 1.0 to 1.5 kg (varies by configuration)

Product Use:

The IS200AEPCH1BAA module is used for applications requiring precise analog output control. It plays a critical role in industrial automation systems by controlling the output to various devices such as:

• Turbines
• Generators
• Actuators
• Valves
• Motors
