GE+IP-QUADRATURE

Description

Product Name:

GE (GE Automation or GE Industrial Solutions) ip orthogonal module

Features:

The orthogonal encoder signal is processed to determine the absolute or relative axis position.
The rotation speed and direction are calculated from the encoder signal frequency.
The processed position and speed data are provided to the PLC or controller for control.

Product parameters and specifications (depending on module model):

Number of channels: Supports connection to one or two orthogonal encoders.
Input resolution: Specifies the number of revolutions that the module can detect. The higher resolution allows for more precise positioning.
Input voltage: The voltage range compatible with the encoder signal.
Output type: Format of the position and speed data sent to the controller (e.g., pulse train, digital data).
Installation mode: Physical installation mode of the module in the controller system enclosure.
