GE+IC698PSD300C

Description

The GE IC698PSD300C is a power supply module designed for use in industrial control systems.

**Product Name:**

GE IC698PSD300C Power Supply Module

**Product Description:**

The IC698PSD300C is a DC power supply module manufactured by GE (General Electric) as part of their RX3i series of PACSystems. It is designed to provide reliable and stable power to various components within industrial automation and control systems. The module ensures consistent voltage output to support the operation of other modules and devices in the system.

**Product Parameters and Specifications:**

– **Input Voltage:** 24 VDC nominal (18-30 VDC)
– **Output Voltage:** 5 VDC and 24 VDC
– **Output Current:**
– 5 VDC: 5.5 A
– 24 VDC: 2.8 A
– **Power Consumption:** 40 W maximum
– **Isolation:** 1500 VAC isolation voltage between input and output
– **Efficiency:** Typically 85%

– **Environmental Ratings:**

– Operating Temperature: 0°C to +60°C (32°F to 140°F)
– Storage Temperature: -40°C to +85°C (-40°F to 185°F)
– Relative Humidity: 5% to 95% non-condensing
– **Mechanical Dimensions:**
– Width: 1 slot (30 mm)
– Height: 112 mm (4.41 in.)
– Depth: 99 mm (3.90 in.)

**Product Use:**

The IC698PSD300C power supply module is used primarily in industrial applications where reliable power distribution is critical for the operation of various control and automation components. It is commonly integrated into GE’s RX3i PACSystems, providing the necessary voltage levels to ensure uninterrupted operation of PLCs (Programmable Logic Controllers), I/O modules, and other field devices. The module’s compact design and robust performance make it suitable for deployment in diverse industrial environments, ranging from manufacturing plants to utility facilities.
