Description

The IC698CRE040 and IC698CRE030 are part of General Electric’s (GE) Industrial Control Systems, specifically within their Programmable Logic Controller (PLC) offerings under the RX3i series.

Product Names:

• IC698CRE040: RX3i Ethernet Communication Processor
• IC698CRE030: RX3i Ethernet Communication Processor

Product Descriptions:

• IC698CRE040:
  • The IC698CRE040 is an Ethernet Communication Processor designed to enable communication between the RX3i PLC system and other devices over Ethernet. It supports various protocols, facilitating the integration of other automation devices and distributed control systems.
• IC698CRE030:
  • Similar to the IC698CRE040, the IC698CRE030 serves as an Ethernet Communication Processor for the RX3i PLC system. It also supports a range of communication protocols, enabling effective data exchange and control between devices.

Product Parameters and Specifications:

• General Specifications:
  • Voltage: Typically operates on 24V DC power supply.
  • Form Factor: Modular design, fitting into the RX3i rack.
  • Operating Temperature: Designed to operate in a range of industrial environments.
• IC698CRE040 Specifics:
  • Communication Ports: Minimum of two Ethernet ports for network redundancy.
  • Protocols Supported: Ethernet/IP, Modbus TCP, and more.
  • Status Indications: LED indicators for monitoring operational status.
• IC698CRE030 Specifics:
  • Communication Ports: Similar multi-port capabilities to support network communications.
  • Network Speed: Supports standard Ethernet speeds (e.g., 10/100 Mbps).
  • Diagnostics: Built-in diagnostics and error logging features.

Product Use:

• Industrial Automation: Both modules are primarily used in manufacturing and processing industries where PLC systems are utilized for automation.
• Data Exchange: Enable seamless communication between different devices such as sensors, actuators, and other PLCs.
• Networked Control Systems: Useful in systems requiring distributed control and monitoring, allowing for real-time data exchange and control capabilities.

Applications:

• Manufacturing: Line control, process automation, and machine control.
• Building Management: HVAC control, lighting control systems.
• Water Treatment: Pump control, monitoring, and reporting.
• Safety Systems: Integrating safety interlocks and alarms.
