GE+IC698CPE040-JP

Description

The GE IC698CPE040-JP is a module from the GE Fanuc series of industrial automation products.

Product Name:

IC698CPE040-JP – GE Fanuc CPU Module

Product Description:

The IC698CPE040-JP is a Programmable Logic Controller (PLC) Central Processing Unit (CPU) module designed for use in GE Fanuc’s Series 90-30 PLC system. This particular model, with the JP suffix, indicates it is a variant intended for the Japanese market. The CPU is the central part of the PLC system that controls and processes inputs and outputs based on user-programmed logic. It features high-speed processing capabilities, supports a wide range of I/O modules, and offers robust communication options.

The module is typically used in industrial automation applications to control machinery, processes, and other equipment that require real-time processing and decision-making. It supports both local and remote I/O modules and can be integrated into more extensive control systems, including SCADA and HMI systems.

Product Parameters and Specifications:

• Model: IC698CPE040-JP
• Product Type: CPU Module for Series 90-30 PLC
• Microprocessor: Motorola 68K-based architecture (or similar)
• Memory:
  • 128 KB user memory (expandable with external memory)
  • 1MB to 2MB of EEPROM for program storage
• Processing Speed: Approximately 100 µs per instruction, depending on configuration
• Power Requirements:
  • Operating voltage: 5V DC ± 5%
  • Power consumption: 10W typical (depending on connected modules)
• Input/Output Capabilities:
  • The CPU supports communication with up to 16 I/O racks.
  • Supports up to 128 I/O modules connected directly to the CPU.
  • Digital I/O, analog I/O, and specialty modules are available for integration.
• Communication Ports:
  • Built-in serial ports (RS-232, RS-485) for communication with other devices (HMI, SCADA, remote I/O, etc.)
  • Support for Ethernet communication (for certain configurations or with add-ons).
  • GE Fanuc Serial Communication Protocol (for direct communication with other GE equipment).
• Operating Temperature Range: 0°C to 60°C (32°F to 140°F)
• Storage Temperature Range: -40°C to 85°C (-40°F to 185°F)
• Environmental Protection: Designed for standard industrial environments with dust, humidity, and vibration tolerance.

Product Use:

The IC698CPE040-JP CPU module is primarily used for controlling automated processes in various industries. Some of the main applications include:

1. Manufacturing Automation: Used to control production lines, robotic arms, conveyors, and other machinery.
2. Process Control: Applied in industries such as oil & gas, water treatment, and chemical processing, where real-time data processing and control are critical.
3. Building Automation: Used in systems for controlling heating, ventilation, air conditioning (HVAC), and lighting.
4. Packaging and Material Handling: Manages automated equipment for sorting, labeling, and packaging items in warehouses or production plants.
5. Energy Management: Controls electrical systems, such as motor drives and power distribution equipment, ensuring operational efficiency.
6. Remote Control & Monitoring: Can communicate with supervisory control and data acquisition (SCADA) systems for remote monitoring and management.

In these applications, the IC698CPE040-JP provides real-time control and decision-making, ensuring that industrial systems operate reliably and efficiently.

Additional Features:

• High Flexibility: Compatible with a wide range of I/O and communication modules.
• Expandability: The system can be expanded by adding more I/O racks or upgrading the CPU for more processing power.
• Programmability: Typically programmed using GE Logicmaster or Proficy Machine Edition software.
• Reliability: GE’s Series 90-30 PLCs are known for their high reliability in mission-critical industrial environments.
