GE+IC670ALG310

Description

The GE+IC670ALG310 is a module from General Electric’s (GE) series of industrial control and automation products. It belongs to the GE Fanuc or GE Automation & Controls product line, specifically designed for use in control systems, often in industrial and manufacturing environments.

Product Name:

GE+IC670ALG310

Product Description:

The IC670ALG310 is an analog input module used in GE’s Series 90-30 programmable logic controller (PLC) systems. This module is designed to interface with various analog field devices and convert the input signals into a digital format that can be processed by the PLC. It supports a range of input types, making it suitable for applications in industries such as manufacturing, process control, and automation.

Product Parameters and Specifications:

1. Input Channels:
   • Typically, this module features 8 analog input channels.
   • Each channel can be configured for either voltage or current input signals.
2. Input Signal Range:
   • Voltage input: 0 to 10V, -10V to +10V, or other ranges depending on configuration.
   • Current input: 4-20 mA.
3. Resolution:
   • The module provides high-resolution analog-to-digital conversion, often around 12 bits or better.
4. Signal Conversion:
   • The module converts the analog input signal to a digital format that can be interpreted by the PLC for control logic.
5. Accuracy:
   • The typical accuracy for voltage and current input signals is within ±0.1% or better, depending on specific conditions and calibration.
6. Input Impedance:
   • High input impedance for voltage inputs, typically greater than 1 MΩ.
   • Low input impedance for current inputs, designed to work with 4-20 mA loop systems.
7. Power Supply:
   • The module typically requires a 24V DC power supply to operate.
8. Environmental Specifications:
   • Operating temperature: 0°C to 60°C (32°F to 140°F).
   • Storage temperature: -40°C to 85°C.
   • Relative Humidity: 5% to 95% non-condensing.
9. Mounting:
   • Designed to be mounted on a GE Series 90-30 PLC rack, which facilitates easy integration into control systems.
10. Communication:
    • The module communicates with the CPU and other modules via the PLC backplane.
11. Isolation:
    • The module typically includes channel-to-channel isolation, which is crucial for minimizing the risk of electrical noise or faults.

Product Use:

• Industrial Automation: The IC670ALG310 module is used to monitor analog sensors and devices in applications like temperature sensors, pressure sensors, flow meters, and other process variables.
• Process Control Systems: It helps in collecting analog data from the field and transmitting it to the central PLC, enabling the automation of various industrial processes.
• Manufacturing Systems: Used to gather and process data from production machinery to ensure smooth and efficient operations.
• Building Management Systems: In HVAC or energy management systems, it can be used to read input from various sensors such as temperature and humidity controllers.

GE+IC670ALG310
