FOXBORO+FBM219

Description

The FOXBORO+FBM219 is a specific module in the Foxboro series of process control and automation products. It is designed to be used in industrial environments for process control systems and typically integrates into distributed control systems (DCS).

Product Name:

FOXBORO FBM219

Product Description:

The FOXBORO FBM219 is an I/O (input/output) module used within the Foxboro I/A Series Distributed Control System (DCS). It is designed to interface with field devices and sensors, facilitating the monitoring and control of process parameters in various industrial applications, such as oil & gas, chemicals, power generation, and manufacturing.

This module is a part of the Fieldbus Interface Module (FBM) series, and it typically supports analog and digital I/O operations. The FBM219 is specifically configured to handle a broad range of communication protocols and provides efficient data acquisition and control over a wide variety of process inputs and outputs.

Product Parameters:

• Model Number: FBM219
• Series: Foxboro I/A Series
• I/O Types: Mixed Analog and Digital
• Power Supply: Typically powered by a 24V DC or AC input
• Signal Types: 4-20 mA, 0-10 V DC (for analog), and digital (for discrete signals)
• Fieldbus Protocol: HART or FOUNDATION Fieldbus
• Number of Channels: Varies depending on the configuration (typically 8 or more)
• Environmental Rating: IP rated for industrial environments, designed for high vibration, temperature extremes, and other harsh conditions
• Temperature Range: -40°C to +70°C (subject to product specifications)
• Mounting: DIN rail or panel mount

Specifications:

• Dimensions: Approx. 4.3” x 9.2” x 4.8” (varies with model)
• Weight: 0.7 – 1.2 kg (depending on the model configuration)
• Communication Protocols:
  • Modbus
  • HART
  • FOUNDATION Fieldbus
• Accuracy:
  • Analog Input: ±0.1% of full scale (for certain models)
  • Digital Input/Output: Typically ±1% for reliable switching
• Current Input/Output: 4-20 mA, 0-20 mA
• Voltage Input/Output: 0-10 V, 0-5 V DC
• Status Indication: LED indicators for system status, communication status, and I/O points

Product Use:

The FOXBORO FBM219 module is primarily used in industrial process control applications where data acquisition and real-time control are crucial. It is used in Distributed Control Systems (DCS) to:

• Monitor sensor data (temperature, pressure, flow, etc.)
• Interact with field devices like transmitters, sensors, actuators, and valves
• Provide communication over various industry-standard protocols like HART or FOUNDATION Fieldbus
• Offer flexibility in dealing with both analog (e.g., temperature, pressure) and digital (e.g., on/off, status) signals
• Enable centralized data collection, control, and process management

Typical applications include:

• Oil and Gas: Monitoring pressure, temperature, and flow in pipelines and refineries
• Chemical Plants: Control of various chemical process variables such as pressure, level, and temperature
• Power Generation: Energy generation, turbine control, and process flow monitoring
• Water and Wastewater Treatment: Monitoring and controlling flow rates, chemical injection, and water treatment processes

This module is a key part of Foxboro’s I/A Series that integrates various control elements to improve process automation, reduce downtime, and increase the efficiency of operations.

FOXBORO+FBM219
