Description

Product Name:

Bently Nevada 3500/45 Dynamic Pressure Transmitter Module

Product Description:

The Bently Nevada 3500/45 is designed for monitoring and protection of industrial machinery by measuring dynamic pressure within machinery such as compressors, turbines, and pumps. The module is part of the larger Bently Nevada 3500 Series and is used to integrate dynamic pressure transducers with the 3500 monitoring system to measure real-time dynamic pressure fluctuations.

The module provides highly accurate pressure readings, which help in detecting potential issues such as imbalance, misalignment, and mechanical failure in machinery. The 3500/45 is compatible with a wide range of dynamic pressure transducers, delivering reliable readings in harsh industrial environments.

Product Parameters:

• Input Type: Supports dynamic pressure transducer inputs (typically 4-20 mA).
• Power Supply: Standard 24V DC or system-specific supply voltages.
• Measurement Range: The range of the dynamic pressure measured depends on the transducer used.
• Output: Analog outputs to communicate pressure data to the central monitoring system (e.g., the 3500 system).
• Signal Conditioning: Provides signal conditioning for the pressure signal to ensure accurate measurement and integration.
• Data Logging: Can provide historical data for trend analysis when connected to the 3500 system.

Product Specifications:

• Power Requirements:
  • Voltage: 24 V DC nominal
  • Current: Typically < 1.0 A (depending on configuration)
• Input/Output:
  • Input: 4-20 mA (from dynamic pressure transducers)
  • Output: 4-20 mA or digital communication via 3500 system
• Operating Temperature: -40°C to +70°C (-40°F to +158°F)
• Environmental Protection:
  • Designed for industrial environments with robust protection against shock, vibration, and humidity.
• Compatibility:
  • Works with Bently Nevada 3500 system (requires appropriate configuration with the 3500 rack and other modules).
• Dimensions (approx.):
  • Width: 2.5 inches (6.35 cm)
  • Height: 8.5 inches (21.59 cm)
  • Depth: 3.5 inches (8.89 cm)
• Mounting: Typically rack-mounted in a 3500 series system enclosure.

Product Use:

The Bently Nevada 3500/45 Dynamic Pressure Transmitter Module is used in industrial condition monitoring and protection systems. It is specifically used to monitor dynamic pressure signals in machinery such as:

• Turbines: to detect early signs of mechanical issues that could affect performance.
• Compressors: for monitoring pressure anomalies that could lead to failures.
• Pumps: to detect unusual pressure changes or potential failure points.
• Generators and other rotating machinery: to ensure reliable performance and reduce downtime.
