BENTLY+3500/22M 138607-01

Description

The Bently Nevada 3500/22M 138607-01 is part of the 3500 Series of machinery monitoring systems, widely used in industries for predictive maintenance, machinery protection, and condition monitoring.

Product Name:

Bently Nevada 3500/22M 138607-01

Product Description:

The Bently Nevada 3500/22M 138607-01 is a vibration monitoring module designed for machinery protection and condition monitoring systems. It is used to measure and monitor the vibration and displacement of rotating equipment such as motors, turbines, pumps, and compressors in industrial applications. The module provides real-time diagnostics, monitoring, and alerting, helping to prevent unplanned downtime and improving asset reliability.

This module is specifically designed to interface with other components in the 3500 Monitoring System and provide data that is crucial for predictive maintenance strategies. It is compatible with various sensors that measure machine vibration, displacement, and other critical parameters.

Product Parameters and Specifications:

• Model: 3500/22M 138607-01
• Type: Vibration Monitoring Module
• Compatibility: Part of the Bently Nevada 3500 Series (other modules such as the 3500/20, 3500/53, etc.)
• Sensor Inputs:
  • Vibration sensors (Accelerometers)
  • Displacement sensors (Proximity probes)
  • Typically used with eddy current or LVDT sensors.
• Measurement Range:
  • Vibration Displacement: Typically up to 2 inches (50.8mm)
  • Vibration Velocity: Depending on the sensor, ranges may go from 0.01 to 500 inches per second (ips)
  • Acceleration: Common ranges up to 1000 g (depending on sensor specification)
• Signal Processing:
  • Digital processing for high accuracy.
  • Real-time measurement updates and diagnostics.
• Communication Protocols:
  • Supports Bently Nevada’s proprietary protocols, or Modbus for integration with third-party systems.
  • Integration with Bently Nevada 3500 System or other monitoring systems via rack-mounted modules.
• Power Requirements:
  • Typically 24 V DC (but varies based on the configuration).
  • May have redundant power supply options for critical applications.

Product Features:

• Real-Time Monitoring: Continuous vibration and displacement monitoring to detect imbalances, misalignments, and other issues.
• Alarm & Shutdown: Configurable alarm levels and automatic machine shutdown options to prevent catastrophic failure.
• Signal Conditioning: Advanced signal conditioning allows it to work with a variety of sensors.
• Integrated Diagnostics: Helps identify the cause of machinery problems with accurate fault diagnostics and trends.
• Data Logging & Trending: Provides historical data collection for predictive maintenance and troubleshooting.

Product Use:

The Bently Nevada 3500/22M 138607-01 is primarily used in industries that rely on rotating machinery, such as:

• Power generation (e.g., turbines, generators)
• Oil and gas (e.g., pumps, compressors, turbines)
• Chemical processing (e.g., reactors, mixers, pumps)
• Mining (e.g., mills, crushers)
• Water treatment facilities
• HVAC systems (e.g., large air handling units)

It is employed for:

• Condition Monitoring: Helps operators track the health of critical machinery in real-time, providing insights into operational anomalies.
• Predictive Maintenance: By analyzing trends in vibration, displacement, and other parameters, the system can predict when maintenance is needed, reducing the risk of unexpected breakdowns.
• Machinery Protection: Acts as a protective layer against catastrophic failures by providing early warnings of impending faults (e.g., imbalance, misalignment).
