AB+MVI56-BAS

Description

The AB+MVI56-BAS module refers to a Modular I/O Communication Interface used in industrial automation and control systems. Specifically, it is part of the Allen-Bradley (AB) range of modules designed for use in automation systems to interface with programmable logic controllers (PLCs). The MVI56-BAS module is typically used in a Rockwell Automation system, helping to connect Allen-Bradley controllers to different types of networks or external devices.

Product Name:

Allen-Bradley MVI56-BAS (BAS module)

Product Description:

The MVI56-BAS module is a communication interface module designed to integrate Allen-Bradley ControlLogix or CompactLogix systems with third-party devices and networks. It serves as an interface to BAS (Building Automation Systems) protocols, making it easier to link industrial automation with building systems like HVAC, lighting, and security systems.

It uses an open architecture, typically for controlling or integrating industrial building systems through Modbus, BACnet, or other common protocols. The module provides bidirectional communication between a ControlLogix system and the various BAS protocols, improving control, monitoring, and data exchange.

Product Parameters and Specifications:

1. Module Type:
   • Communication interface (Gateway)
   • Compatible with Allen-Bradley ControlLogix and CompactLogix PLCs
2. Input Voltage:
   • 24V DC (typical for ControlLogix and CompactLogix systems)
3. Operating Temperature:
   • Standard range: 0°C to 60°C (32°F to 140°F)
   • Storage temperature: -40°C to 85°C (-40°F to 185°F)
4. Protocols Supported:
   • Modbus RTU/TCP
   • BACnet/IP and BACnet MS/TP
   • Ethernet/IP
   • ASCII Protocols (in some configurations)
5. Communication Ports:
   • One or more Ethernet/IP port(s) for network connectivity
   • Optional RS-232/RS-485 serial communication port (depending on configuration)
6. Data Capacity:
   • The MVI56-BAS module supports multiple BAS device connections (depending on the network configuration and protocols supported).
7. Mounting:
   • Can be mounted on a standard 1756 chassis or used in a CompactLogix system with an appropriate interface module.
8. Status Indicators:
   • LED indicators for operational status, including network activity and module health.
9. Communication Speed:
   • Typically supports standard communication rates for the respective protocols, e.g., 10/100 Mbps for Ethernet and adjustable speeds for serial connections (RS-232/RS-485).
10. Dimensions:
    • Height: 4.65 in (118 mm)
    • Width: 3.8 in (97 mm)
    • Depth: 1.5 in (38 mm)

Product Use:

The MVI56-BAS module is mainly used for:

1. Building Automation Integration: It connects industrial automation control systems (like PLCs) to building management systems, enabling monitoring and control of HVAC, lighting, energy management, fire alarms, and other building systems.
2. Data Exchange: Facilitates seamless communication between various devices and controllers operating on different protocols, ensuring that Modbus, BACnet, and other industrial protocols can be integrated into a unified system.
3. Energy Monitoring: Used in applications requiring energy consumption monitoring and management through BAS systems.
4. Facility Management: It allows plant managers and facility operators to integrate and centralize data from various building systems into a single automated control platform.
5. Industrial Automation: Enables control of HVAC systems, lighting, access control, and other systems from a central automation platform, offering centralized control and advanced analytics.

AB+MVI56-BAS
