ABB+UNITROL 1020

Description

The ABB UNITROL 1020 is a product used in the field of electrical power systems, specifically for the control and regulation of electrical generators and power grids. It is a part of ABB’s broader range of power control systems, commonly applied in power plants, substations, and industrial installations.

Product Name:

ABB UNITROL 1020
Power System Stabilizer and Automatic Voltage Regulator (AVR)

Product Description:

The ABB UNITROL 1020 is an advanced automatic voltage regulator (AVR) and power system stabilizer, designed to ensure stable and reliable operation of generators and power systems. It provides voltage control and dynamic performance optimization for electrical generators, maintaining voltage stability even during changes in load, generation, and network conditions. It is widely used in power plants, industrial sites, and electric grid systems.

The UNITROL 1020 is known for its high-performance capabilities in regulating voltage, improving power system stability, and providing protection against faults. It uses sophisticated algorithms and control technology to provide automatic adjustment of the generator voltage, frequency, and other important electrical parameters.

Product Parameters & Specifications:

• Voltage Control Range:
  • Voltage regulation typically in the range of 0-100% of nominal generator voltage.
• Input/Output:
  • Input from the generator’s exciter and output for controlling the excitation system (typically connected to a rotating exciter or static exciter).
• Power Supply:
  • AC or DC power supply (dependent on system design).
• Control Characteristics:
  • Automatic and manual voltage regulation.
  • Automatic compensation for load variations.
  • Dynamic voltage adjustment to maintain system stability.
• Signal Inputs:
  • Voltage and current measurements.
  • Frequency and other auxiliary inputs.
• Control and Communication:
  • Advanced algorithms for optimized voltage regulation.
  • Integrated communication interfaces (e.g., Modbus, Profibus, or other proprietary communication protocols).
• Protection Features:
  • Overvoltage and undervoltage protection.
  • Fault detection and automatic corrective actions.
• Stabilization:
  • Power system stabilizer (PSS) functionality to mitigate oscillations and enhance stability in power networks.
  • Harmonic compensation.
• User Interface:
  • Local HMI (Human-Machine Interface) for system control and monitoring.
  • Optional remote monitoring and control capabilities.
• Temperature Range:
  • Typically designed to operate in environments with temperatures ranging from -10°C to +55°C (depending on the installation site).
• Mounting:
  • Rack-mounted or panel-mounted, depending on the system requirements.
• Compliance:
  • Complies with international standards such as IEC, ANSI, and UL (varies by region and application).

Product Use:

The ABB UNITROL 1020 is used in a variety of industrial and power generation applications where maintaining stable voltage and system stability is critical. Common use cases include:

1. Power Plants:
   • Ensures voltage regulation for synchronous generators.
   • Stabilizes grid frequency and voltage during generation fluctuations.
2. Industrial Applications:
   • Used in heavy industrial plants where generators need to maintain stable operation.
3. Electric Grid Management:
   • Helps control generator output to ensure stable operation of the power grid, especially in environments with fluctuating loads.
4. Renewable Energy:
   • Can be used in renewable energy setups (such as wind or hydroelectric plants) to stabilize power output and maintain voltage levels.
5. Marine or Offshore Platforms:
   • In systems where power supply reliability is critical and generators need continuous regulation.
6. Stand-Alone Power Systems:
   • Provides voltage and stability control in isolated or off-grid electrical systems.

Key Benefits:

• Enhanced Voltage Regulation: Ensures continuous voltage stability, even in fluctuating load conditions.
• Improved System Stability: Helps reduce system oscillations and enhances power quality.
• Flexible Integration: Easily integrates with a wide range of generator and excitation systems.
• Reduced Downtime: Provides protection and fault detection to minimize operational disturbances.
• Remote Monitoring: Can be monitored and controlled remotely for more efficient operation and maintenance.
