ABB+UCD240A101 3BHE022287R0101

Description

The ABB UCD240A101 (3BHE022287R0101) is a power module typically used in industrial and automation applications.

Product Name:

ABB UCD240A101 (3BHE022287R0101)

Product Description:

The UCD240A101 is part of ABB’s series of DC-DC converters, designed to provide stable and efficient power supply solutions for various industrial and automation systems. This specific module typically functions as a power supply module in control systems, with particular applications in providing isolated DC voltages for automation, communications, and instrumentation purposes. It is engineered to meet high reliability and efficiency standards.

Product Parameters and Specifications:

• Input Voltage Range:
  • DC Input: 24V (Nominal) DC with a typical range of 18V to 30V DC.
• Output Voltage:
  • 5V DC (nominal output), used to power logic circuits and controllers.
• Output Power Capacity:
  • Rated output power: Typically 30W or more, depending on the specific variant or load requirements.
• Efficiency:
  • High conversion efficiency (typically up to 90% or higher) to minimize energy loss and heat generation.
• Output Current:
  • Typically up to 6A (depending on the exact configuration and application).
• Operating Temperature Range:
  • The module can typically operate within -20°C to +60°C.
• Isolation:
  • Provides galvanic isolation between input and output to prevent electrical noise and interference from affecting sensitive components.
• Form Factor:
  • Compact and modular design, suitable for DIN rail mounting and integration into industrial control cabinets.
• Short-circuit and Overload Protection:
  • Equipped with overload and short-circuit protection to ensure reliability and protect connected devices.
• Dimensions:
  • Standard size suitable for mounting in industrial control panels, with specific dimensions depending on the configuration.
• MTBF (Mean Time Between Failures):
  • High MTBF value, indicating long service life in industrial environments.

Product Use:

• Industrial Automation Systems: Used for providing isolated 5V DC power to control systems, sensors, and communication devices in industrial automation.
• Control Panels and PLCs: Can be integrated into control panels to power logic circuits and programmable logic controllers (PLCs).
• Telecommunications Equipment: Used in telecommunications systems to ensure stable operation and reduce electromagnetic interference.
• Process Control and Instrumentation: Provides reliable power for sensors, actuators, and other control equipment.

Key Features:

• High Efficiency: Reduces power consumption and heat generation.
• Wide Input Voltage Range: Ensures stable operation across a wide range of input voltages.
• Isolation: Prevents issues caused by ground loops and electrical noise in sensitive equipment.
• Compact and Robust: Designed for use in industrial and rugged environments.

This power module is typically used in industrial and automation systems where stable, isolated, and efficient DC power conversion is critical to the performance of control systems, sensors, and devices.

ABB+UCD240A101 3BHE022287R0101
