Description

The ABB SYNCHROTACT 5 (3BHB006713R0217) is a controller used for synchronizing and paralleling generators in power plants.

Product Name:

ABB SYNCHROTACT 5 (3BHB006713R0217)

Product Description:

The SYNCHROTACT 5 controller is designed to ensure the smooth synchronization of generators to the power grid. It monitors parameters such as voltage, frequency, and phase angle to safely connect generators in parallel with each other and the grid.

Product Parameters and Specifications:

Voltage Input: 100-240 V AC, 50/60 Hz
Operating Temperature: -10°C to +50°C
Control Functions: Voltage control, frequency control, phase angle control
Display: LCD screen for real-time monitoring of parameters
Communication Interfaces: RS-485, Modbus RTU protocol
Protection Features: Over-voltage protection, under-voltage protection, over-frequency protection, under-frequency protection
Accuracy: High precision in synchronization (typically within 1 degree of phase difference)

Product Use:

The SYNCHROTACT 5 controller is used primarily in power plants, particularly in situations where multiple generators need to be synchronized before connecting to the grid. It ensures that the generators operate in harmony with each other and the grid, preventing electrical disturbances and ensuring stable power supply.

This controller plays a crucial role in maintaining grid stability and optimizing the efficiency of power generation systems by enabling seamless synchronization and parallel operation of generators
