ABB+SD822 3BSC610038R1

Description

The ABB SD822 3BSC610038R1 module is a Control Network Expansion Module.

Product Name:

ABB SD822 3BSC610038R1 Module

Product Description:

The ABB SD822 module is a Control Network Expansion Module that is designed to expand the control network capabilities of certain ABB products.

Product Parameters:

– Part Number: SD822 3BSC610038R1
– Maximum Current: Up to 1A per channel
– Communication Protocol: PROFIBUS DP
– Communication Speed: Up to 12 Mbps
– Number of Channels: 1
– Power Supply: 24 VDC

Specifications:

– Operating Temperature: -25 to 60 degrees Celsius
– Storage Temperature: -40 to 85 degrees Celsius
– Humidity: 5% to 95% non-condensing
– Dimensions: 90 x 68 x 120 mm (W x H x D)

Product Use:

The ABB SD822 module is used in industrial automation applications to expand and enhance the control network capabilities of ABB products. It allows for communication between different devices on the network, enabling efficient and reliable data exchange for seamless operation of the automation system.
