ABB+REF620E_F NBFNAAAANDA1BNN1X

Description

The ABB REF620E_F NBFNAAAANDA1BNN1X module is a member of the ABB Relion 620 series of feeder protection and control relays.

Product Name:

ABB REF620E_F NBFNAAAANDA1BNN1X Module

Product Description:

The REF620E_F is a highly advanced and configurable protection relay designed for protecting power distribution networks. It offers a wide range of protection functions, communication capabilities, and flexibility in application. With its compact design and robust construction, it is suitable for use in demanding environments.

Product Parameters and Specifications:

– Rated Voltage: 100-240 V AC/DC
– Frequency: 50/60 Hz
– Communication Interfaces: IEC 61850, Modbus, DNP3
– Ethernet Communication: Ethernet ports for connection to SCADA systems
– Protection Functions: Overcurrent protection, under/overvoltage protection, directional protection, frequency protection, and more
– Inputs/Outputs: Multiple digital and analog inputs/outputs for custom applications
– Display: LCD display for local monitoring and control
– Mounting: DIN-rail or panel mounting options

Product Use:

The ABB REF620E_F NBFNAAAANDA1BNN1X module is primarily used in substations and distribution networks for the protection and control of feeder circuits. It can be used to detect and isolate faults in the network, prevent damage to equipment, and ensure the stability and reliability of the power system. The relay can be configured and customized to meet the specific requirements of the application, making it suitable for use in a wide range of utility and industrial settings.
