Description

### Product Name:

ABB REF615C E HCFEAEAGABC2BAA11E

### Product Description:

The ABB REF615 is a digital protection relay designed specifically for the protection, control, and monitoring of medium-voltage (MV) networks. It is part of ABB’s REF615 relay family, which is known for its versatility and advanced functionalities tailored to meet the needs of electrical utilities and industrial applications. The REF615C E model comes with enhanced communication and connectivity features, making it suitable for a range of applications in power systems.

### Product Parameters and Specifications:

1. **Protection Functions:**
– Overcurrent Protection (OC)
– Earth Fault Protection (EOF)
– Voltage Protection (UV / OV)
– Frequency Protection (Under/Over Frequency)
– Distance Protection (if applicable)
2. **Communication Protocols:**
– IEC 61850
– DNP3
– Modbus
– Profibus (optional)
3. **Inputs/Outputs:**
– Digital Inputs: Typically 8 to 16 configurable inputs
– Digital Outputs: Typically 8 to 16 configurable outputs (relays or logic)
– Analog Inputs: Current and voltage measurements
4. **Measuring Accuracy:**
– Current Measurement: ±1% of reading
– Voltage Measurement: ±1% of reading
5. **Power Supply:**
– Voltage Range: Typically 48-250 V DC or AC
– Power Consumption: Generally low to ensure efficiency
6. **Enclosure:**
– Standard: Outdoor/indoor (depending on the configuration)
– Protection Class: Generally IP54 or higher, depending on the model
7. **User Interface:**
– LCD Display: For real-time status and settings
– Configurable LEDs: For indicating system status
8. **Software:**
– Configuration and Monitoring Tools: Compatible software for setup and analysis (e.g., PCM600)
9. **Dimensions:**
– Size varies by model; typically designed for rack or panel mounting.

### Product Use:

The ABB REF615C E controller is primarily used in:

– Medium voltage switchgear applications for substation automation.
– Industrial electrical systems that require effective protection and control.
– Utility applications for feeder protection and control.
– Integration within smart grid initiatives, providing detailed status monitoring and fault information.
– Enhancement of reliability and operational efficiency in electric distribution systems.

This relay enhances system protection and enables efficient monitoring and control of electrical networks, which is critical for ensuring power distribution reliability and safety.
