Description

The ABB REF610 is a protective relay designed for the protection, control, and monitoring of electrical distribution systems, particularly for medium-voltage networks.

Product Name:

ABB REF610 3BHB005171R0101

Product Description:

The ABB REF610 is a versatile and reliable relay that provides comprehensive protection functions for power transformers and feeders. It supports various protection schemes and is equipped with advanced communication capabilities, making it suitable for modern smart grid applications. The REF610 is designed to enhance the reliability and efficiency of electrical distribution networks.

Product Parameters:

• Input Voltage: Typically designed for rated voltage levels in the range of 100-250 VAC.
• Operating Frequency: 50/60 Hz.
• Protection Functions:
  • Overcurrent protection (phase, ground)
  • Earth fault protection
  • Voltage protection (undervoltage, overvoltage)
  • Differential protection
  • Thermal overload protection
• Communication Protocols: Supports IEC 61850, Modbus, and other protocols.
• Display: LCD display for parameter monitoring and settings.
• Event Logging: Records fault events and system disturbances for analysis and troubleshooting.

Specifications:

• Dimensions: Compact design for easy integration into panels.
• Operating Temperature Range: -20°C to +55°C.
• Power Supply: Can operate from various input voltage sources, typically 20-60 V DC for auxiliary power.
• Protection Class: Designed to meet various environmental and safety standards.
• Weight: Specific weight may vary, but generally lightweight for ease of installation.

Product Use:

The REF610 is primarily used in:

• Medium Voltage Distribution: To protect transformers, feeders, and motors in medium voltage applications.
• Industrial Applications: Suitable for various industrial sectors including oil and gas, mining, and manufacturing.
• Renewable Energy Systems: Can be integrated into wind and solar energy generation setups for reliable protection.
• Smart Grids: Plays a critical role in smart grids and automation solutions, providing real-time monitoring and control.
