ABB+REF610 3BHB005171R0101

Description

The ABB REF610 (3BHB005171R0101) is a numerical relay module primarily used for the protection and control of electrical motors and generators.

**Product Name:**

ABB REF610 (3BHB005171R0101)

**Product Description:**

The ABB REF610 is a member of the REF610 series of numerical relays designed for motor and generator protection. It provides comprehensive protection functionalities and advanced control capabilities to ensure the safe and efficient operation of electrical machines.

**Product Parameters and Specifications:**

– **Voltage:** Supports various voltage levels depending on the specific application.
– **Current:** Handles different current ratings typically encountered in motor and generator protection.
– **Frequency:** Compatible with standard electrical frequencies (50 Hz and 60 Hz).
– **Communication Interfaces:** Offers multiple communication options such as Modbus, IEC 61850, and DNP3, facilitating integration into different control and monitoring systems.
– **Protection Functions:** Includes overcurrent protection, differential protection, thermal protection, and other specialized protection functions tailored for motor and generator applications.
– **Control Functions:** Provides advanced control features like motor start-up, synchronization, and load shedding.
– **Event Recording:** Stores event and disturbance records for diagnostic purposes.
– **Human-Machine Interface (HMI):** Equipped with a user-friendly interface for local monitoring and control.
– **Redundancy Options:** Supports redundancy configurations to enhance reliability in critical applications.

**Product Use:**

The ABB REF610 (3BHB005171R0101) module is used in various industrial applications where the protection and control of electrical motors and generators are essential. Its primary functions include protecting equipment from electrical faults, optimizing operational efficiency, and ensuring safety during operation.

This relay module is typically found in industries such as:

– **Power Generation:** Including both conventional and renewable energy sectors.
– **Industrial Manufacturing:** Where electrical motors and generators are extensively used.
– **Utilities:** Ensuring reliable distribution and protection of electrical power.

Overall, the ABB REF610 (3BHB005171R0101) module is recognized for its robust design, advanced functionalities, and flexibility in addressing diverse protection and control requirements in industrial settings.
