ABB+PP825 3BSE042240R1

Description

The ABB PP825 3BSE042240R1 is a touch screen display device used in industrial automation and control systems, particularly as part of ABB’s 800xA process control system.

Product Name:

ABB PP825 3BSE042240R1 – Touch Screen

Product Description:

The ABB PP825 is a human-machine interface (HMI) touch screen used to interact with ABB’s automation and control systems. It is designed for seamless operation within the 800xA and S+ Control environments, allowing operators to monitor and control processes efficiently. The device features a graphical interface and touch-sensitive display, providing an intuitive way to interact with the system. It offers high-resolution visuals, long-lasting performance, and rugged construction for industrial environments.

Product Parameters and Specifications:

1. Model: PP825 3BSE042240R1
2. Type: Touch Screen HMI
3. Screen Size: 15-inch (diagonal measurement)
4. Display Type: TFT LCD with a high resolution
5. Resolution: Typically 1024 x 768 (XGA), depending on configuration
6. Touch Interface: Resistive or capacitive touchscreen (depending on version)
7. Power Supply: 24V DC (common for industrial HMIs)
8. Communication Interfaces:
   • Ethernet/IP
   • Modbus TCP
   • CANopen or other industrial protocols (based on setup)
9. Operating System: Typically embedded OS such as Windows CE or Linux
10. Operating Temperature Range: Usually between -10°C to +55°C
11. Mounting: Panel or rack-mounted (depending on model variant)
12. Protection Rating: Typically IP65 (front side), suitable for industrial environments
13. Input/Output Ports: USB, RS232/RS485, and possibly others (specific to your model)
14. Software Compatibility: Integrated with ABB’s 800xA and S+ Control software for process automation and control

Product Use:

• Human-Machine Interface (HMI): The PP825 touch screen is designed for operators to interface with complex process control systems in industries such as power generation, oil & gas, chemical manufacturing, and water treatment. Operators can monitor real-time data, configure control parameters, and visualize process states.
• Visualization of Process Data: The display provides a graphical user interface to present real-time operational data such as alarms, system status, and performance indicators.
• Control and Monitoring: Enables control over automation processes, with touch-based interaction to adjust setpoints, acknowledge alarms, and modify system parameters.
• Data Logging and Reporting: It is capable of logging and displaying historical data and trends, which is vital for system diagnostics and performance reviews.
