ABB+PM864AK01 3BSE018161R1

Description

The ABB PM864AK01 3BSE018161R1 is a specialized module used in the ABB 800xA Distributed Control System (DCS), often associated with advanced automation and control in industrial environments.

Product Name:

ABB PM864AK01 3BSE018161R1 — Processor Module

Product Description:

The PM864AK01 is a powerful processor module designed for use in ABB’s 800xA control systems. It serves as the core component for high-performance control and monitoring in a wide range of industrial automation applications, including energy, oil and gas, and manufacturing industries. This module handles complex calculations, logic execution, and data communication within the control system.

The PM864AK01 is designed for redundancy in critical applications, offering improved performance and reliability. It is equipped with powerful processing capabilities, and its architecture is optimized for high-speed, secure, and fault-tolerant operations, crucial for real-time control systems.

Product Parameters and Specifications:

• Model: PM864AK01
• Part Number: 3BSE018161R1
• Processor Type: Dual-core ARM-based processor
• System Compatibility: Compatible with ABB 800xA DCS
• Memory: Typically has 16 GB of RAM (specific configurations may vary)
• Power Supply: Typically operates at 24V DC
• Operating Temperature:
  • Range: 0°C to 55°C (standard operating temperature range)
• Communication Ports:
  • Ethernet: Supports Ethernet-based communication (e.g., TCP/IP, MODBUS)
  • Redundancy: Features system redundancy for fail-safe operation
• I/O Support:
  • Supports a large number of I/O devices via ABB’s various I/O modules
  • Integration with field devices and other control system elements is possible via FIELDBUS, PROFIBUS, and Modbus
• Dimensions:
  • Typically around 12.7 x 4.8 x 5.5 inches (Dimensions may vary based on specific configuration)
• Mounting: Rack-mounted or panel-mounted depending on system design
• Environmental Rating: IP20 (suitable for indoor use)

Key Features:

1. High-Performance Processing:
   The PM864AK01 processor provides powerful computational capabilities for real-time control, enabling precise control and monitoring.
2. Redundancy Support:
   It offers built-in redundancy features for improved system reliability, making it ideal for mission-critical operations that cannot afford downtime.
3. Integrated Communication Support:
   It supports a variety of industrial communication protocols, ensuring seamless integration with existing infrastructure.
4. Energy Efficient:
   The processor is designed to consume minimal power while delivering high performance.
5. Flexible Integration:
   The module integrates easily with other ABB control components and third-party devices via standard industrial communication protocols.
6. Real-time Monitoring:
   It offers real-time processing capabilities for efficient operation and monitoring in large-scale systems.
7. Firmware/Software Support:
   The PM864AK01 operates with ABB’s Control Builder and other software tools, enabling easy configuration, diagnostics, and maintenance.

Product Use:

The PM864AK01 processor module is used in a variety of industries and applications, including:

• Process Control Systems: Managing complex processes in industries such as petrochemical, chemicals, power generation, and water treatment.
• Manufacturing Automation: Controlling robotic systems, production lines, and packaging.
• Energy Management: Used in smart grids, substation automation, and power distribution systems.
• Oil & Gas: Control of production processes, pipelines, and off-shore platforms.
• Building Automation: Integrated into systems managing HVAC, lighting, and security.

ABB+PM864AK01 3BSE018161R1
