ABB+PM864AK01 3BSE018161R1

Description

Product Name:

• ABB+PM864AK01 3BSE018161R1

Product Description:

The PM864AK01 is a processor module designed for the ABB 800xA system or Advant Controller 400 (AC 400). It serves as the central processing unit for handling complex control operations and communication tasks in industrial automation systems. This processor is used in a wide range of applications such as process control, machinery control, and automation in industries like power generation, oil and gas, manufacturing, and more.

The PM864 module comes equipped with high-speed processing capabilities, support for advanced communication protocols, and extensive I/O options. It acts as a bridge between field devices, controllers, and higher-level control systems.

Product Parameters & Specifications:

• Processor type:
  32-bit processor with high-speed performance suitable for real-time control and monitoring.
• Operating system:
  The module typically operates with ABB’s 800xA Control Software or AC 400 system.
• Memory:
  • RAM: Typically, 4 MB of RAM or higher (depending on specific configurations).
  • Non-volatile memory: Includes flash storage for program and configuration retention.
• Communication protocols:
  • Supports Ethernet and serial communication.
  • Compatibility with standard industrial communication protocols like Modbus, PROFIBUS, Modbus TCP, EtherNet/IP, and HART.
• I/O support:
  • The PM864 module interfaces with I/O modules that can be used to control or monitor field devices.
  • Flexible I/O expansions can be connected for scalability in large systems.
• Power Supply:
  • Typically requires a 24V DC power supply.
• Environmental Ratings:
  • Operating temperature: 0°C to 60°C (varies with specific model configurations).
  • Storage temperature: -40°C to 85°C.
  • Humidity range: 5% to 95% (non-condensing).
• Mounting:
  • DIN rail or rack mounting options depending on the system setup.
• Dimensions:
  • Width: Typically around 150mm (varies depending on configuration).
  • Height: About 100mm.
  • Depth: Around 20mm to 30mm.
• Input/Output (I/O):
  The PM864 module does not typically have built-in I/O but interfaces with various I/O modules in a distributed control system. These I/O modules can support both analog and digital signals, with remote I/O possibilities for flexibility in system architecture.

Product Use:

The ABB PM864AK01 module is primarily used in automation and control systems for:

• Industrial process control in industries such as chemical, oil & gas, and power generation.
• Data acquisition and remote monitoring of field devices.
• Real-time control for complex systems like batch processing, machinery, and robotics.
• Integration in the ABB 800xA control system, enhancing its ability to handle large-scale, complex automation tasks.

Applications:

• Process Control: Handling control logic for processes like temperature regulation, pressure control, or flow measurement.
• Machine Control: Managing machinery operation in manufacturing lines, ensuring synchronization between machines.
• Data Communication: Seamlessly communicating data between the control system, field devices, and SCADA systems.
• Safety Systems: Providing fail-safe operations and interlocks in critical processes to ensure safety.

ABB+PM864AK01 3BSE018161R1
