Description

Product Name

ABB PM802F Power Meter Controller

Product Description

The ABB PM802F is a high-performance power meter designed for precise monitoring and control of electrical energy. It offers advanced measurement capabilities, comprehensive communication options, and robust functionality for managing power quality and efficiency. The device is ideal for various applications, including industrial, commercial, and utility environments.

Product Parameters and Specifications

• Measurement Capabilities:
  • Voltage: Up to 600 V AC
  • Current: Up to 10 A (with external CTs for higher values)
  • Power: Active, reactive, and apparent power
  • Energy: Active and reactive energy measurement
  • Frequency: 45 Hz to 65 Hz
• Accuracy:
  • Class 0.5 for active energy
  • Class 1 for reactive energy
• Display:
  • LCD display with backlight
  • Multiple parameters displayed simultaneously
  • Customizable display screens
• Communication:
  • Modbus RTU (RS-485)
  • Ethernet/IP
  • Profibus DP
  • Various protocols for easy integration into existing systems
• Inputs and Outputs:
  • Digital inputs for alarms
  • Relay outputs for control functions
  • Analog outputs (optional)
• Power Supply:
  • Wide input range: 85–265 V AC/DC
• Environmental Conditions:
  • Operating Temperature: -25°C to +55°C
  • Humidity: 5% to 95% (non-condensing)

Product Use

The ABB PM802F power meter controller is used for:

• Monitoring electrical parameters in real-time to ensure efficient energy usage.
• Identifying and diagnosing power quality issues, such as harmonics and voltage sags.
• Collecting and analyzing data for energy management and optimization.
• Integrating with energy management systems for reporting and compliance.
• Providing critical data for preventive maintenance and system improvements.

This device is particularly useful in sectors like manufacturing, building automation, and utilities, helping organizations reduce energy costs and enhance operational efficiency.
