ABB+PM630

Description

The ABB PM630 is a power meter module used for energy management and monitoring in industrial and commercial settings.

**Product Name:**

ABB PM630 Power Meter Module

**Product Description:**

The ABB PM630 is a versatile power meter module designed to accurately measure electrical parameters in real-time. It is part of ABB’s comprehensive portfolio of energy management solutions, offering precise monitoring capabilities essential for optimizing energy usage, ensuring system reliability, and improving overall efficiency. The PM630 is suitable for a wide range of applications including building management systems, industrial automation, and renewable energy installations.

**Product Parameters and Specifications:**

– **Electrical Measurements:** Voltage (V), Current (A), Power (kW, MW), Energy (kWh, MWh), Power Factor, Frequency
– **Accuracy:** Class 0.5 according to IEC 62053-22
– **Communication Interfaces:** Modbus RTU, Modbus TCP/IP, Profibus DP, Ethernet
– **Display:** LCD Display for local readings
– **Input Voltage:** 100-240V AC, 50/60 Hz
– **Digital Inputs/Outputs:** Configurable for various control and alarm functions
– **Environmental Specifications:** Operating Temperature: -10°C to +55°C, Storage Temperature: -25°C to +70°C, Humidity: 5% to 95% non-condensing
– **Dimensions:** Compact DIN-rail mounted module

**Product Use:**

The ABB PM630 power meter module is used primarily for:

– **Energy Monitoring:** Provides detailed insights into energy consumption patterns, allowing for informed decision-making in energy management strategies.
– **Power Quality Analysis:** Measures parameters like harmonics, voltage dips, and swells to ensure compliance with power quality standards and optimize equipment performance.
– **Load Management:** Enables efficient load balancing and peak demand management, contributing to reduced energy costs and enhanced operational efficiency.
– **System Integration:** Interfaces with SCADA (Supervisory Control and Data Acquisition) systems and other industrial automation platforms for seamless integration into existing infrastructures.

The PM630 is an essential component in ABB’s range of solutions aimed at enhancing energy efficiency, reliability, and sustainability across industrial and commercial applications. Its robust design, coupled with advanced measurement capabilities, makes it suitable for demanding environments where accurate and reliable power monitoring is crucial.

ABB+PM630
