ABB+IMDS014

Description

The module is part of ‘s digital output module series designed for automation and control applications.

**Product Name:**

ABB+IMDS014 Module

**Product Description:**

The is a digital output module that provides reliable and high-performance output capabilities for various industrial automation tasks. It is designed to interface with control systems to manage and control external devices such as actuators, motors, and other digital output devices.

**Product Parameters:**

– **Channels:** 16 digital output channels
– **Voltage Range:** 24 V DC
– **Current Rating:** Up to 0.5 A per channel
– **Isolation:** Optically isolated outputs
– **Response Time:** Typically less than 1 ms

**Specifications:**

– **Module Type:** Digital Output Module
– **Mounting:** DIN rail mountable
– **Operating Temperature:** -25°C to +60°C
– **Storage Temperature:** -40°C to +85°C
– **Humidity:** 5% to 95% RH, non-condensing
– **Dimensions:** Standard DIN 43880 housing, 124 mm height

**Product Use:**

The module is used in industrial automation systems where precise control and monitoring of digital outputs are required. Typical applications include:

– Controlling actuators and solenoids
– Driving relays and motors
– Switching lights and alarms
– Managing digital signals in PLC (Programmable Logic Controller) systems

This module is suitable for a wide range of industries including manufacturing, process control, energy, and utilities, where reliable and efficient digital output control is essential for operational success.
